KEY FACTORS IN LEGACY SYSTEMS MIGRATION

A Real Life Case

Teta Stamati, Konstantina Stamati, Drakoulis Martakos

Department of Informatics and Telecommunications, University of Athens,Panepistimiopolis, Athens, Greece

Keywords: Legacy systems, migration methodology, drivers, hinders, critical success factors.

Abstract: Although legacy systems migration as a subject area is often overlooked in favour of areas such as new

technology developments and strategic planning of information technology, most migration projects are

considered ill-fated initiatives and a rate of over 80% of these projects run over budget, frequently with

system functionality falling short of contract. Many practitioners consider that the proposed theoretical

migration approaches are myopic and do not take into account a number of key factors that make a

migration project a really complex initiative. Our position is that throughout the life cycle of a migration

process, there are some critical factors that initially play the role of the “drivers” and afterwards they

became the factors that hinder (“hinders”) the migration process. We consider these key factors as Critical

Success Factors (CSF) that must be carefully considered. Furthermore, these key factors could be either

overt or covert factors. In each case, the migration engineers should consider and analyse them very

carefully prior to the initiation of the migration process and a well-defined migration methodological plan

should be developed. The work presented is based on a real life initiative putting emphasis on the key

success factors revealing at the same time the complexity of a migration process. Emphasis is put on the

required management view and planning effort, rather than on the mere technological issues.

1 INTRODUCTION

The term “legacy system” is one of the most widely

used and somewhat misconstrued terms in the

industry today. It describes an old system that

remains in operation within an organisation and

often represents a massive, long-term business

investment that could be composed of extremely

efficient robust and fine tuned applications built over

many years by a combination of IT and business

experts. Moreover, the term “legacy” is used in a

pejorative sense to describe applications based on

old and obsolete technology. In general, the legacy

applications represent the storehouse of business

intelligence to support and manage core business

functions and provide critical information for day-

to-day operations. In fact, legacy applications,

especially those based on mainframe platforms, are

the mainstays of today’s businesses.

Several alternative definitions of what exactly a

legacy system is can be retrieved. Ulrich (1994)

defined them as “stand-alone applications built

during a prior era’s technology, but they are perhaps

more widely understood as software systems whose

plans and documentation are either poor or non-

existent (Connall and Burns, 1993)”. Bennett (1995)

referred to the legacy systems as “large software

systems that we do not know how to cope with but

that are vital to the organisation”, while Brodie &

Stonebraker (1995) as “any information system that

significantly resists modification and evolution to

meet new and constantly changing business

requirements”. In all the aforementioned definitions,

often the notion of “something valuable” is present,

as well as the notion of “old and obsolete” (Lauder

and Lind, 1999). It is unambiguously recognised that

legacy systems are crucial for the operation of

organisations and thus they are essential for our

economical and well-fare activities.

The commonsense solution for an organisation to

the legacy problem is migration of its mission

critical legacy systems. The definition of a

successful information system migration according

to Brodie & Stonebraker (1995) is as follows: “it

begins with a mission-critical legacy system of a

significant size in full operation and it ends with a

fully operational, mission critical target application

(or applications components) that replace the

340

Stamati T., Stamati K. and Martakos D. (2006).

KEY FACTORS IN LEGACY SYSTEMS MIGRATION - A Real Life Case.

In Proceedings of the Eighth International Conference on Enterprise Information Systems - DISI, pages 340-344

DOI: 10.5220/0002469403400344

 SciTePress

essential aspects of the original legacy system”. This

involves replacing the problematic hardware and

software, including the interfaces, applications and

databases that compose an information system

infrastructure. Brodie & Stonebraker (1995) claim

that legacy information system migration involves

starting with a legacy information system and ending

with a comparable target information system. This

target system is significantly different from the

original, but it contains substantial functionality and

data from the legacy system.

Within this context, the main objective of the

present work is to refer to a specific case of a

mission critical migration initiative revealing some

significant factors that should be seriously

considered by both migration engineers and business

experts during the life cycle of a legacy systems

migration initiative. The case described is based on a

spin-off migration project for the Supply Chain

Management (SCM) Department of a Greek Public

Organisation (hereinafter referred to as “the

Organisation”).

For reasons of confidentiality, there is no

reference to the name and nature of the Public

Organisation as well as some details in this

experience are made somewhat more generic, but

the conclusions remain sufficiently based on a real

experience to be relevant in some contexts.

2 DRIVERS AND HINDERS AS

CRITICAL SUCCESS FACTORS

The main mission of the Organisation’s SCM

Department is the general support of all the in-house

supply chain management processes, their provided

services as well as the satisfaction of requirements

of distinct Units within the Organisation.

2.1 The Context of the Case

In the beginning of 1999 the Organisation published

a Request for Proposal (RFP) initiating the

evaluation procedure of outsourcing the migration

process of its mission critical mainframe system to a

new architecture. The RFP requested the most

effective and efficient methodology in order to

transfer the legacy functionality (legacy system) to a

new environment (target system). The case was

mainly driven by the need to revitalise the

Organisation’s IS infrastructure that was crucial for

the SCM Department and focused on the need to

reengineer its large scale legacy environment. More

specifically, the objective was twofold: the “2000

problem” resolution as well as the development of a

new information system that would include all the

existing operational functionality as well as the new

operational requirements that had been raised by the

obligation of conformity with the introduced

logistics regulation for the Greek Public Sector.

The duration of the tenders’ evaluation process

was four months and an integration company

(hereinafter referred to as “the Integrator”) was

selected among several candidates as the most

appropriate company to implement the project.

The main argument that the Integrator had used

in order to gain the tender was that the company had

already developed a well-defined methodological

approach called “Bridge Migration” method in order

to successfully implement prior migration initiatives

mainly in the Banking Sector.

The “Bridge Migration” approach was based on

the use of gateways in order to successfully handle

the transformation from the legacy system to the

new environment. A robust combination of the state

of the art methodologies for successful migration

had been included within the Integrator’s technical

proposal and based on its proved know-how, the

company promised to the Organisation the

immediate customisation of the “Bridge Migration”

approach to the specific needs of the Organisation.

The main principles of the approach were as

follows:

− transfer all the legacy data activities to the

target within a narrow time frame acceptable

by the legacy system.

− restart/recover after a system failure all of the

data in all technology platforms involved.

− reconcile and account of data and immediate

availability of the data to the users of the

corresponding applications.

− incorporate into the system the auditing

functionality on data transferred and system

status reporting.

− handle processing of the errors, exceptions and

rejections, stemming from referential integrity

constraints, data errors and/or technical

reasons. Individual rejected transactions would

be selectively resubmitted for processing or

dropping from the system.

− consider the inter-dependencies between the

applications and provide a mechanism to

service these dependencies during operation.

− provide priority levels on data transfers, so that

emergency updates and back-log bypass would

be allowed.

KEY FACTORS IN LEGACY SYSTEMS MIGRATION - A Real Life Case

341

− facilitate the roll-out of the target system and

the shut-down of legacy system.

− include tools for the operation and monitoring

of the system. Parameters governing

functionality, such as start/stop times or data

commit frequency, could be integrated within

the system. The legacy system could

dynamically set these parameters on an

individual file interface level. Also, the one-to-

many routing of data from target to legacy

would be table driven and dynamically

determinable.

− include an interface for correcting data

inconsistencies resulting from lack of

synchronization between target and legacy. It

could as well report on such off-line events.

− apply a large volume data changes, such as

batch updates not depending on system’s

operation and availability.

The Integrator’s underlying philosophy of

implementing the project was that the engineering

team involved in the project had the know-how to

successfully implement migration projects and it

could make the specific approach fit to the

Organisation’s requirements.

2.2 Drivers for Legacy Migration

The Organisation’s SCM Department had been

involved in the in-house development of the legacy

system for more that thirty years. The system formed

the central hub and the backbone of the information

flow within the Department and was the main

vehicle for consolidating information about the

supply chain management processes.

The old system was built in COBOL with an

obsolete Command Line Interface and the data were

stored in Index (flat) COBOL Files.

The Organisation’s legacy system was posing

numerous and important problems to the host

Department. Some of the worst and lamentably

typical key characteristics that played the role of the

“drivers” in the system level for having the system

migrate and evolve were the following:

− it was too large, with millions of lines of code.

Furthermore, it was too old (more than thirty

years old).

− it was written in COBOL which was

considered a legacy language. The later

resulted in a situation where there was a

significant loss of institutional knowledge as

the original developers were retired.

Furthermore, the Department was facing a

skills shortage as the academic institutes had

already stopped teaching the COBOL.

− it was built around a legacy database service

namely, flat-files.

− it was running on obsolete hardware, which

was slow and expensive to maintain.

− the growing business volume and the data

processing model used made the system

performance an increasingly important issue.

− maintaining the software of the legacy system

was an expensive task and the process of

finding and correcting system faults was also

costly and time consuming because of the

significant lack of documentation and a

general lack of understanding of the internal

functionality of the system.

− lack of clean interfaces brought obstacles in

the integration process with other systems.

− it could not evolve to accommodate new

functionality that was required by the

Organisation.

To complicate matters, the system was

considered as mission-critical and had to be

operational at all times. It was difficult to modify the

system while it continued to perform its mission-

critical functions.

Additionally to the aforementioned “drivers” as

far as the system was concerned there was as well a

significant number of business “drivers” for having

the system migrate, as follows:

− the Department’s attempt to redefine its

strategy from a traditional data processing

model to a multi-channel, service oriented

model. This enforced the requirement to have

up-to-date data, coming from multiple sources,

on-line at all times. It should be noted that the

data was often replicated at local offices, for

historical reasons and the historical data was

often only available off-line, e.g. archived on

tape.

− the coming of the year 2000 would generate to

the system the well-known problem of the

dates.

− legal requirements and regulations in Greece

for the Public Sector were under investigation

and potential changes hardly ever consider the

IT system characteristics.

ICEIS 2006 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

342

2.3 Hinders of Legacy Migration

The initial timeframe of the project prescribed the

completion of the whole initiative within less than

eight months. This short period of time for such a

complicated project had been considered as an

imposed constraint that the project team had to

adhere to. Due to that short project life cycle the

Department considered that there was no time and

need to produce from scratch the functional

requirements for the part of the applications that

would replace the legacy functions. The main

underlying argument of the project steering

committee was that ultimately the target system

should have exactly the same functionality as the old

one as far as the existing

functionality was

concerned.

The combination of the millions of lines of

COBOL code with the lack of documentation and

comments within the code proved to be a serious

obstacle for the in-depth understanding and analysis

of the code in order for the involved team to obtain

the detailed knowledge of the existing functionality.

This was the main reason that the ultimate required

man-months for completion of the migration process

were much more than the initial estimation of the

man-effort within the project plan. Considering the

aforementioned “hinders” factors, the project

steering committee decided to proceed to the

following scenario: separation of the whole code in

functional groups, removal of the redundancies and

keeping the core applications blocks in COBOL.

Afterwards, the engineering team built new

functionality around these core COBOL applications

and linked them with a new relational database and

windows-based interface and reporting tools.

The project delivered to the Organisation after

eight moths and the project’s committee considered

the new system as a fully operational and successful

system. Thus, although the new target system

consisted of some “old” parts of the legacy system

(COBOL applications) preventing potential further

enhancement of the target system, the project’s

steering committee decided that the new system

covered their current needs.

3 CRITICAL SUCCESS FACTORS

OF LEGACY MIGRATION

Due to the complexity that a migration initiative

reveals, a well-defined methodological action plan is

required (Stamati et al., 2004). This plan should

consider in detail all the CSFs which could play

initially the role of the main motivators that drive the

migration need and afterwards could be constraints

that hinder the same process. Thus, it is necessary to

produce a well designed plan of the whole process as

far as the methodological perspective is concerned.

The technology drive should be present, but should

not be overestimated.

In our case, a more careful evaluation of the “as-

is” situation in the initial mainframe environment

was required. Relevant action items were among

others the evaluation of the pre-existing COBOL

code and the underlying data structures.

Determination of the “to-be” business and

application architecture along with the

corresponding “to-be” technical and deployment

architecture were essential for the completion of the

project. Furthermore, critical evaluation of the

migration scenario between the “as-is” and the “to-

be” situations should have been further analyzed and

designed in depth.

Each migration process must be gradual (Holland

and Light, 1999). We should not proceed to a

decision of a big band migration or to a short period

initiative. This could add constraints to the decision

that narrow the ultimate result of the system.

Finally, the success of a migration effort has to

be measurable (Sommerville, 2001). In our case, it is

noteworthy that the whole project plan was

continually adapted considering the new obstacles

and constraints. Although the project’s steering

committee was fully satisfied with the target

delivered system, the lack of a well defined list of

CSFs that would have been used to evaluate the

process should have been considered as essential for

the final validation of the system.

Therefore, a number CSF’s must be defined.

Those should not only be used to evaluate the final

outcome, but should be used along the road to

measure progress and to define decision points in the

plan, where go/no-go decisions must be made.

In this particular case, the following indicative

CSF’s could identify that:

− a significant proof of concept must be

delivered within a narrow amount of time and

effort

− along the whole roadmap, quick wins must be

identified to validate the migrating system, and

those must offer a measurable business benefit

− support from the stakeholders must

continuously be ensured

The Department provided to the Integrator the requirements’

handbook as far as the new additional functionality was

concerned.

KEY FACTORS IN LEGACY SYSTEMS MIGRATION - A Real Life Case

343

o from management

o from users, both business and regular

Generally, the CSFs should mirror the successful

implementation of a migration project. The CSFs

during a migration initiative must ensure that the

requirements and specifications should be

completed, the assertions must be testable and

detailed requirements must be done jointly.

Executive support, clear vision, well-defined

business objectives, good project management,

definition of a formal process, firm basic

requirements, skilled staff and user involvement are

considered as imperative factors for the success of

such projects. Acceptance criteria should be initially

defined considering the required functionality, the

test cases and the performance targets. User

management commitment is essential as well.

Managers should be results-oriented, act as internal

champions for the migration project and be

committed to a user/developer partnership model.

Finally, quality assurance and performance metrics

should be considered as key factors.

4 CONCLUSIONS

Any effort for migration or evolution of large-scale

industrial software systems must be driven by a

corporate strategy redefinition. Buy-in from

management and end users requires a well-defined

strategic management view and planning, based on a

clear statement of motivation, objectives and of the

constraints imposed by the current environment and

continuous operational needs. Thus, any migration

process must be implemented as a planned change

process that first and foremost requires an

understanding of the range of issues and

organisational entities involved. The definition of

measurable success factors is essential. The

organization-wide methodology must be defined and

supported by all stakeholders.

ACKNOWLEDGEMENTS

Much of the work presented in the sections above

was undertaken under the research project called

PYTHAGORAS: Help of Research Teams in the

Universities, that is part-financed by the Operational

Program of Education and Initial Professional

Training-EPEAEK and the European Fund-EKT.

REFERENCES

Bennett, K.H., 1995. Legacy Systems: Coping With

Success. In IEEE Software, 12(1), 19-23.

Brodie, M.L. & Stonebraker, M., 1995. Migrating Legacy

Systems, Morgan Kaufmann Publishers. London, 2

edition.

Connall, D. & Burns, D., 1993. Reverse Engineering:

Getting a Grip on Legacy Systems. In Data

Management Review.

Holland, C., P. and Light, B., 1999. Focus issue on Legacy

Information Systems and Business Process Change:

Introduction. In Communications of AIS, 2(9), 98-120.

Lauder, A. and Lind, M., 1999c. Legacy Systems: Assets

or Liabilities?, In LAP'99, Copenhagen.

Sommerville, I., 2001. Software Engineering. 6

Edition,

Pearson Education.

Stamati, T., Kanellis, P., Stamati, K., Martakos, D., 2004.

Legacy Migration as Planned Organizational Change.

In Sixth International Conference on Enterprise

Information Systems (ICEIS) 3, 501-508.

Ulrich, W., 1994. From Legacy Systems to Strategic

Architectures. In Software Engineering Strategies,

2(1), 18-30.

ICEIS 2006 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

344
