MODELLING E-BUSINESS SECURITY USING BUSINESS

PROCESSES

S. Nachtigal

Royal Holloway, University of London

Egham, Surrey TW20 0EX, UK

C. J. Mitchell

Royal Holloway, University of London

Egham, Surrey TW20 0EX, UK

Keywords:

e-business, information security model, business process, information ﬂows, perimeter security.

Abstract:

Organisations (enterprises, businesses, government institutions, etc.) have changed their way of doing busi-

ness from a traditional approach to embrace e-business processes. This change makes the perimeter security

approach inappropriate for such organisations. The well-known and widely used security mechanisms, in-

cluding cryptography-based tools and techniques, cannot provide a sufﬁcient level of security without being a

part of a comprehensive organisational approach/philosophy. This approach must be different from the current

dominant approach, i.e. perimeter security, and must focus on different organisational components. In this

paper we suggest a process security approach, and describe ongoing research with the aim of developing an

e-business security model based on this new, process security, approach.

1 INTRODUCTION

The way in which business is conducted is going

through a very signiﬁcant change. E-business, a new

and different way of running a business, is a subject

of growing importance both for the business and the

academic world.

The business world has adopted information tech-

nology since the very early stages of computer his-

tory. From mainframes, through minicomputers, PCs

and LANs, to WANs and EDI — all these tech-

nologies (combining hardware, software, databases

and telecommunications) provide a company with the

means to enhance its internal operations. Informa-

tion technology has changed signiﬁcantly since the

introduction of computers, while these technology

changes have impacted business practice to a great

extent (Oz, 2000). In value chain/supply chain terms,

information technology has helped to improve the ef-

ﬁciency of company supply chains (Poirier and Bauer,

2001); WANs and EDI were the ﬁrst technologies

adopted to improve external operations by provid-

ing communications with the business environment

(mostly suppliers), and actually extending the supply

chain.

In today’s technology intensive reality, the oppor-

tunity of adding value to the ﬁrm’s supply chain can

be achieved by making more and more business func-

tions ‘electronic’. In technological terms, this is

achieved by introducing increasing numbers of infor-

mation systems and information technologies into en-

terprise business processes and between business pro-

cesses. In other words, this is achieved by networking

the business functions inside the organisation, and be-

tween the organisation and its environment. The In-

ternet infrastructure and Internet-based technologies

make it possible for organisations to perform all busi-

ness connections electronically — not just with sup-

pliers and customers, but also with ﬁnancial insti-

tutions, government bodies, potential suppliers, po-

tential customers, partners, competitors, etc. Use of

Internet-based technologies implies the existence of a

Web-site as a means of enabling electronic business

(Poirier and Bauer, 2001).

In practice, it is possible to transform the sup-

ply chain to an electronic form either partly or com-

pletely, while operating as an e-business organisa-

tion. By doing so, the traditional supply chain be-

comes a supply network. More than that, by introduc-

ing advanced information technologies into the sup-

ply chain, the supply chain becomes, according to

Porter’s model (Porter, 1980), a value chain — i.e.,

a value network or electronic value network.

Given the above discussion, in this paper (and in

the research it is related to) an e-business (e-biz) or-

ganisation is deﬁned as:

459

Nachtigal S. and J. Mitchell C. (2006).

MODELLING E-BUSINESS SECURITY USING BUSINESS PROCESSES.

In Proceedings of the International Conference on Security and Cryptography, pages 459-464

DOI: 10.5220/0002103404590464

 SciTePress

a ‘Business that performs its supply chain ac-

tivities by means of Internet-based Information

Technologies through integration, cooperation

and interaction of its and others supply chain par-

ticipants’ webs, and by doing that actually cre-

ates a Portals Value Network (PVN).’

(It should be emphasised that the research de-

scribed below distinguishes between the terms ‘e-

business’ and ‘e-commerce’. Since we have al-

ready deﬁned the term ‘e-business’, the distinction

should be clear: the term ‘e-commerce’ refers only

to the activities of buying /selling products. Hence e-

commerce is just a part of e-business. The subject of

concern here is ‘e-business’).

Based on our deﬁnition, from a business point

of view, e-business is the integration of processes,

systems and enterprises, while from a technological

point of view, e-business is the collection and inte-

gration of IT concepts and tools. E-business means

that the entire enterprise becomes an e-enabled or-

ganisation. The e-biz approach to performing busi-

ness transactions implies using information technolo-

gies (especially communication technology) through-

out the business supply chain. In fact the electronic

supply chain might be different for each organisation

that practices e-business — depending on the num-

ber and type of organisations that the company has

business relationships with. New threats and prob-

lems arise while using Internet technology in gen-

eral, and especially when a company adopts the e-

biz mode. E-biz involves performing business inter-

actions (in other words, transmitting documents, i.e.

data ﬂow) between organisation portals by means of

Internet technology.

Academic research, while interacting with the busi-

ness world, contributes to mutual efforts to solve ﬁeld

problems. In the case of e-biz, both business and

academia are challenged to provide solutions, since

e-biz is relatively new, and also very beneﬁcial for

various aspects of modern life. As an integration of

business and technology, e-biz faces signiﬁcant difﬁ-

culties and problems. This paper describes ongoing

research related to probably the most signiﬁcant of

these problems, namely security.

2 THE MAIN PROBLEM OF

E-BIZ ORGANISATIONS

The uniqueness, and the danger, in e-biz is its ‘open-

ness’ to the environment, and the various connections

and communication channels with the external world.

As a result of that ‘openness’, an enterprise that prac-

tices e-biz is exposed to a wide range of threats, i.e.

factors that expose the enterprise to a danger of suffer-

ing from loss, both tangible (e.g. monetary loss) and

non-tangible (e.g. reputation).

An e-biz process is subject to all the beneﬁts

and disadvantages that the technologies imply. The

vast majority of the technology-related disadvantages

are information security related — while perform-

ing a process by means of IT, threats such as sensi-

tive (business and private) information disclosure and

theft, industrial espionage, electronic fraud, business

failures due to technological (hardware, software or

communication) failures, viruses, spyware, adware,

phishing, DDoS, impersonation should be considered.

The harm to an enterprise may come from different

sources and by different means— the attacks could

include technology-based tools and methods as well

as social engineering methods.

As IT becomes more and more user-friendly, it also

becomes much more accessible by a wider popula-

tion. The potential sources of security threat sources

are becoming more technology-literate and sophisti-

cated. Although the threats are growing, countermea-

sures are being constantly improved, and new tech-

niques are being applied to secure corporate busi-

ness information; currently, security countermeasures

include hardware and software-based tools and also

powerful cryptographic mechanisms. So, there are in-

creases both in the technological sophistication of the

attackers and in protection methods and power.

However, attackers continue to look for alternative

methods of accessing corporate information. This has

given rise to different kind of threats, based on so-

cial engineering methods, that in the vast majority of

cases have nothing to do with information technology

abuse.

Corporate information systems security has been

dominated by ‘traditional’ security considerations for

many years. According to the traditional information

security model, security is achieved by providing a

security perimeter, designed to protect the company’s

boundaries from the external world (Kis, 2002). The

vast majority of existing business information sys-

tems have been, and are still being, designed and built

according to the perimeter security paradigm. The

goal is to prevent malicious/non-authorised users and

applications from accessing the company and its var-

ious business functions. A wide variety of tools and

mechanisms have been (and are still being) developed

to support corporate security based on this perimeter

security approach.

In this approach, information systems security is

provided on the basis of a trust hierarchy, by which

the internal users (i.e. the company’s employees) are

automatically assigned a maximal level of trust, while

everyone trying to enter the business from the exter-

nal world is assigned a minimal level of trust, if at

all. This approach has a number of shortcomings, in-

cluding the basic assumption that employees can be

trusted (according to CSI’s 2004 statistics, at least

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

460

66% of all security incidents are due to employee ac-

tions, performed either deliberately or by error (CSI,

2005)). Moreover, the concept of ‘closed borders’

ﬁts LAN and/or WAN based activities, but does not

ﬁt so well to Internet-based business operations, and

breaks down completely once one considers mobile

and wireless access to corporate networks.

The traditional business models for information

systems security are thus no longer appropriate, and

ﬁt neither the new organisational environment nor the

new organisational security needs. The old approach

does not distinguish between different applications

with different levels of sensitivity running in the busi-

ness. The different mobile devices, which are poten-

tially widely used in e-biz activities, are at great risk

and could not been given a high trust level, even if

the users are trusted employees. The other problem

is the absence of a standard security infrastructure in

the form of end-to-end protocols: “it is too easy to

steal or tamper with the devices, and the digital keys

are stored at gateways rather than on the device” is a

familiar refrain.

Indeed, we note certain recent developments re-

garding application security — some commercial se-

curity companies have made a declaration on their

new products for application security, while distin-

guishing between different security needs based on

different sensitivity levels. However, there is still no

solution for the security needs resulting from busi-

ness transactions performed via the Internet between

the portals of different participants within the PVN

community. An e-biz company must give access to

its internal various business functions to the external

business world, in order for e-biz to work. A com-

prehensive security solution for such a company must

combine both internal and external information secu-

rity. The task of providing security to the information

systems of such a business mainly involves providing

security for the information transmitted between the

company and the other participants of a speciﬁc PVN

that enables speciﬁc e-biz transactions.

This novel task has arisen from the very deﬁnition

of an e-biz company, and means that e-biz is primarily

concerned with protecting information ﬂows. As a re-

sult, in this paper we focus purely on the information

ﬂows between a company and its PVN participants;

we analyse the security requirements resulting from

such ﬂows in order to obtain an information systems

security model appropriate to e-biz business needs.

3 RELATED WORK

E-business (including e-commerce) is the subject of

a huge volume of ongoing research. Some of this

relates to e-business information security, and just a

small part (with regard to information security) re-

lates to business process and/or information ﬂows.

McLean (McLean, 1990) has developed a ﬂow-based

security model, FM, which is used as a standard

for comparing with other security models. A new

approach (Sabelfeld and Myers, 2003) was recently

developed for specifying and enforcing information

ﬂow policies, since, according to the authors, stan-

dard security practices are not capable of enforcing an

end-to-end conﬁdentiality policy. Other work (Knorr

and Rohrig, 2001) identiﬁes security requirements of

electronic processes. A discussion of e-business pro-

cess modelling (Aissi et al., 2002) offers the building

blocks required for e-business automation, while ad-

dressing the fragmentation of security requirements

as the biggest challenge for Web services.

There is a growing general awareness of the fail-

ings of the perimeter security approach (especially

for e-business). Professional individuals and groups

(such as the Jericho Forum

) have called for an al-

ternative approach, while suggesting a variety of so-

lutions. The objective of this paper is to introduce

such a new approach, namely a business-processes

oriented security model, to e-business enterprise secu-

rity. This new approach is based on an e-biz core char-

acteristic of performing business functions by means

of electronic data and information ﬂows.

4 THE BUSINESS PROCESS

A process, as commonly deﬁned, is the conver-

sion/transformation of a certain entity (tangible or

non-tangible) from one form to another while under-

going a series of actions (Laudon and Laudon, 1998).

A business process can be deﬁned as a certain se-

quence of activities that transforms inputs from dif-

ferent suppliers into outputs to selected customers

(Smith and Fingar, 2003a).

Two universal macro-level modules are present

in any business organisation, namely operations and

management. The operations module is the most ba-

sic; without operations (i.e. processes) there is no

management, and there is actually no organisation.

No organisation is able to function as a vital active

unit without properly performing its processes. A

process can be described by mapping all the docu-

ments carrying the data relevant to the process. An e-

biz process is based on a set of information/data ﬂows

that enable its existence. In practice, the only way

to perform an e-biz process is to transmit documents

over electronic channels, using the speciﬁc technolo-

gies making up the infrastructure that enables busi-

ness communications.

www.opengroup.org/jericho/

MODELLING E-BUSINESS SECURITY USING BUSINESS PROCESSES

461

The existence of the company is dependent (in the

case of e-biz) on the functionality of these electronic

channels (e.g. the functionality of the Internet-related

technologies) and the information they carry, while

the importance of information quality and functional-

ity is becoming a critical factor for all e-biz compa-

nies. Major parts of documents (if not all of them)

include sensitive information; in any case, in order to

ensure that the functionality of the business proceeds

according to plan, all the business data and informa-

tion (both transmitted and stored) should be protected.

This leads us to a conclusion that for an e-biz com-

pany to function properly (and to function at all) its

business processes have to be secured.

Smith and Fingar (Smith and Fingar, 2003a) distin-

guish three different characteristics related to business

processes:

• state — the value of calculations performed, and

the amount of information collected and generated

during the execution of the process;

• capability — the activities and relationships of

communications established between the partici-

pants at any stage of the process;

• design — the intentional characteristics of the pro-

cess, put in place during the design of the process.

Smith and Fingar (Smith and Fingar, 2003a) use these

process characteristics to link business management

and business technology. Dynamics is a signiﬁcant

characteristic of a modern business — not just the

process itself, but also the relationships between the

processes and even the channels of executing the pro-

cesses. A business process, as deﬁned above, in prac-

tice occurs by transforming documents between sta-

tions involved in a speciﬁc series of actions in order

to complete a speciﬁc mission. Documents contain

data essential to perform each one of the procedural

stages of a speciﬁc process. In other words, we use

documents as a convenient way of carrying data.

Focusing on business process security appears to

be a rational approach that complies with the most

basic deﬁnition of ‘organisation’ in respect of its per-

formance on a daily basis. Without processes there is

no business, so providing security to an e-biz process

simply enables the existence of such a business.

5 THE SECURITY MODELLING

PROCESS

Existing security tools and mechanisms, developed

upon the traditional perimeter security concept, and

based on hardware and software products, including

cryptography, are not sufﬁcient since they do not re-

late to speciﬁc parameters that characterise the busi-

ness process. This paper presents ongoing research

that introduces a novel approach to securing business

information systems by focusing on business pro-

cesses.

An e-biz company must give access from the ex-

ternal business world to its internal various business

functions, because only in that way can the e-biz

mode be valid. A comprehensive security solution for

such a company must combine both internal and ex-

ternal information security. The task of providing se-

curity for the information systems of such a business

is mainly concerned with providing a security solu-

tion to the information transmitted between the com-

pany and the other participants of a speciﬁc PVN that

enables speciﬁc e-biz transactions. This task is a new

one that has been arisen from the deﬁnition of an e-biz

company, and becomes the primary focus of e-biz se-

curity. As a result, the research described here will be

limited to that task only; that is the information ﬂows

between the company and its PVN participants will

be analysed in order to obtain an information systems

security model appropriate to e-biz business needs.

As stated above, a process is associated with doc-

uments transmitted between the different stations of

that process. This is why the best way to present a

process is by presenting the information involved (i.e.

that produced, transmitted and stored) in the process.

The business processes could be identiﬁed by describ-

ing the business functions of which the processes are

a part. However, when considering an e-biz process,

there are number of rather unique features of this spe-

ciﬁc kind of a business process. Even the semantics of

the widely used concept of workﬂow cannot be used

for modeling the majority of e-biz processes, because

of the great degree of mobility associated with e-biz

activities (Smith and Fingar, 2003a). There is a for-

mal theory of mobile processes, namely Pi-Calculus

as developed by Milner. Most, if not all, processes

are associated with the mobility feature — see (Mil-

ner, 1999) and (Smith and Fingar, 2003b).

The ‘mobility’ concept seems to be one of the most

signiﬁcant properties of e-biz process; it refers to the

way information is exchanged among the participants

in a process, and the changes in their relationships as

the process evolves during execution. In fact, in the

business environment, all the processes may/should

be considered as mobile processes (Smith and Fingar,

2003a).

As stated before, an e-biz organisation runs its busi-

ness differently to a traditional ﬁrm. Its business pro-

cesses are an integration of sequences and sets of in-

formation ﬂows. (The concept of analysing informa-

tion ﬂows has been used by McCumber in his Mc-

Cumber Cube approach (McCumber, 2005), while

dealing with mapping information ﬂow states and in-

troducing the concept of 3-states information exis-

tence).

This paper introduces a different direction for in-

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

462

formation ﬂow analysis. In order to deﬁne the e-biz

functions and processes, a detailed description of the

well known traditional business functions and pro-

cesses is performed. Any process is viewed as being

comprised of a set (potentially a very complex one)

of speciﬁc information ﬂows. All the processes of the

organisation, and the relevant information ﬂows as-

sociated with them, are described, and the results are

summarised by means of an Information by Processes

Table (IbPT).

In order to secure a business process, not only do

its information ﬂows need to be secured, but also all

the data stores that serve these information ﬂows. In

order to operate properly, e-biz relies on a vast va-

riety of data to support the organisation’s activities.

Besides all the business data and information stores,

there are also stores (packages) of speciﬁc computer

system data, needed for system execution or produced

by the system.

All the processes, together with the associated in-

formation ﬂows, databases and the set of various busi-

ness (operational and management) parameters which

characterise the processes, are evaluated and the ﬁnal

model is formulated. The relationships between the

model components will be deﬁned following the test

phase of the research.

6 USING THE SECURITY MODEL

Organisations are constantly investing in information

technology, and in business information systems se-

curity in particular. These security expenditures have

constantly increased over the last few years (CSI,

2005). The expenditure is mostly on widely used se-

curity tools such as ﬁrewalls, antiviruses, VPNs, en-

crypted channels, etc. Although the tools are effective

to a certain extent, there are objective shortcomings

related to all existing security tools and mechanisms:

1. they solve just the technical side of the security

problem;

2. the acquisition of those tools and mechanisms is

not based on any analytical model, since corporate

management is not supported by any such analyti-

cal model in their decision-making.

According to the traditional perimeter security ap-

proach, security tools are used in order to protect or-

ganisations by preventing certain types of activities

(Holden, 2003) — which potentially results in a cum-

bersome and non-intuitive business environment for

the employees. The security ‘arms race’ is a never-

ending process, since the threats and risks are con-

stantly growing, and the organisation management

never knows how much security is enough to pre-

vent unauthorised access into the business. The re-

sult, again, is the imposition of limitations on em-

ployee operational capabilities (e.g. they are forced

to perform certain business operations in a particular,

highly complex way, at certain hours, certain work-

stations, etc.).

The new approach suggested here, and the model

which comes with it, is designed to to enable business

instead of prevent business by abandoning the con-

cept of borders (which are no longer relevant for an

e-biz company) and providing decision makers with

security measures based on business process speciﬁ-

cations. This is a rational and, therefore, useful tool

since the most important thing for the organisation

is that its business processes are performed properly.

The model will make possible the planning of both

the business security measures and the security man-

agement process itself.

7 TESTING THE MODEL

Because of the nature of the discipline (information

systems security) and the research target, it has been

decided to apply a heuristic case study method in this

research (Myers, 1997). Four different Case Studies

will be performed, for the following reasons.

Any e-biz ﬁrm has to decide upon its business

model, a new and different model to that applying to

a traditional type of business. E-business models can

be grouped and classiﬁed into two categories (Apple-

gate, 2002) — the classiﬁcation should be made on a

basis of separation between two kinds of companies:

• Digital businesses — ﬁrms that are built and

launched on the Internet;

• Businesses that provide the platform upon which

digital businesses are managed and operated.

Gloor (Gloor, 2000) gives a more detailed classi-

ﬁcation of the models suggested by Malone (cited in

(Gloor, 2000)). Malone distinguishes between four

fundamentally different types of models for e-biz:

• Creators — producers of goods (physical or infor-

mation) such as General Electric, Cisco, Dell, Mi-

crosoft, and on-line versions of newspapers.

• Distributors — companies that distribute and/or

supply the goods, such as electronic shops for

books or music (the most representative example

is Amazon).

• Brokers — companies that act as intermedi-

aries, such as on-line auctioneers, travel agen-

cies (eBay, Netaction and Olsale, Thelastminute,

the90minute), are examples of this type of e-biz.

• Extractors — these are companies that exist only

on Internet, operate as portals, and whose business

model is based on advertising revenue. Typical ex-

amples are Yahoo and Google.

MODELLING E-BUSINESS SECURITY USING BUSINESS PROCESSES

463

This classiﬁcation is generic enough and, indeed, in-

cludes all kinds of organisations acting as an e-biz.

Based on the discussions in previous sections, the

next phase of this research with regard with develop-

ment methodology will include the following:

1. The choice of four different e-biz ﬁrms, one for

each of the following types of e-biz models:

• creator;

• distributor;

• broker;

• extractor.

Each of these chosen companies will be used as a

Case Study.

2. Each of the Case Studies will be analysed, covering

the:

• background;

• full process description;

• full information ﬂow description;

• relevant databases;

• security analysis;

• business issues (strategies, policies, etc.).

3. The data will be analysed (the structured data will

be also processed) and discussed.

4. Based on the case study ﬁndings, a ‘process secu-

rity’ model will be developed and formulated.

5. The model (models) will be implemented on the

case study ﬁrms.

8 CONCLUSIONS

Although there is a wide range of technological secu-

rity tools, there is still no solution for security needs

resulting from the business transactions performed,

via the Internet, between the portals of the partici-

pants making up the PVN community. Such a solu-

tion will potentially be very useful for organisations

which practice e-business activity, as discussed above.

Any e-biz organisation will be equipped with a tool

(model) which will enable rational economic security

investments.

Additional beneﬁts will come in form of the infor-

mation acquired during the research phases of testing

the models, i.e. the data collected from the case stud-

ies. These could lead to additional possible research

results. Initially, this data will be used to follow-up

the case-study organisations in order to analyse the

impact of the suggested model in the middle and long

term.

Further, a map of business processes with the asso-

ciated information ﬂows, which will be one of the by-

products of this research, could be a useful basis for

analysing the actual need of various security tools and

measures (in terms of types, amounts, goals, crypto-

graphic strength, etc.), related to a speciﬁc business

process rather than the whole corporation.

REFERENCES

Aissi, S., Malu, P., and Srinivasan, K. (2002). E-business

process modeling: The next big step. Computer,

35(5):55–62.

Applegate, L. M. (2002). E-Business Handbook. The St.

Lucie Press.

CSI (2005). 2004 CSI/FBI Computer Crime and Security

Survey. Computer Security Institute.

Gloor, P. (2000). Making the e-Business Transformation.

Springer-Verlag, London.

Holden, G. (2003). Guide to Network Defense and Coun-

termeasures. Thomson Learning, Course Technology.

Kis, M. (2002). Information security antipatterns in soft-

ware requirements engineering. Permission is granted

to copy for the PLoP 2002 conference.

Knorr, K. and Rohrig, S. (2001). Security requirements

of e-business processes. In Schmid, B., Stanoevska-

Slabeva, K., and Tschammer, V., editors, Towards the

E-Society: First IFIP Conference on E-Commerce,

E-Business, and E-Government; Zurich, Switzerland,

Oct. 4-5, 2001, pages 73–86. Kluwer Academic Pub-

lishers, Norwell, MA.

Laudon, K. C. and Laudon, J. P. (1998). Information Sys-

tems and the Internet. Dryden Press, 4th edition.

McCumber, J. (2005). Assessing and Managing Security

Risk in IT Systems. Auerbach Publications.

McLean, J. (1990). Security models and information ﬂow.

Milner, R. (1999). Communicating and Mobile Systems.

Cambridge University Press.

Myers, M. D. (1997). Qualitative research in information

systems. MIS Quarterly, 21(2):241–242.

Oz, E. (2000). Management Information Systems. Thomson

Learning, Course Technology.

Poirier, C. C. and Bauer, M. J. (2001). E-Supply Chain.

Berrett-Koehler Publishers, Inc.

Porter, M. (1980). Competitive Strategy. Free Press, USA.

Sabelfeld, A. and Myers, A. C. (2003). Language-based

information-ﬂow security. IEEE Journal on Selected

Areas in Communications, 21(1):5–19.

Smith, H. and Fingar, P. (2003a). Business Process Man-

agement: The Third Wave. Meghen-Kiffer Press.

Smith, H. and Fingar, P. (2003b). Workﬂow

is just a Pi process. Possibly available at

www.bpm3.com/picalculus.

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

464
