SECURITY CONSIDERATIONS IN CURRENT VOIP

PROTOCOLS

Steffen Fries

Corporate Technology, Siemens AG, Otto-Hahn-Ring 6, 81730 Munich, Germany

Keywords: Voice over IP, security, encryption, authentication, integrity, SIP, H.323, Megaco, MGCP, SRTP.

Abstract: This document describes current state of the art security functionality provided in the four mainly used and

standardized Voice over IP (VoIP) signaling protocols, as there are the Session Initiation Protocol (SIP),

H.323, Megaco, and the Media Gateway Control Protocol (MGCP). It outlines the security provided by the

protocols itself or by dedicated security extensions including lower layer security protocols like Transport

Layer Security (TLS) or IPSec. Moreover, vulnerabilities, which still remain in protocols or certain scenar-

ios, are depicted as well. Furthermore discussed are also security approaches for the media data provided by

the Secure Real-time Transport Protocol (SRTP) and associated key management schemes. Conclusions are

given by identifying work areas, in which further security related work in the area of multimedia communi-

cation in general and VoIP in specific has to be done.

1 INTRODUCTION

Voice over IP is one of the driving factors for con-

vergent networks. It targets the migration from cur-

rent circuit switched networks to packet based net-

works for voice communication. VoIP is already

being used in enterprise and carrier environments for

VoIP trunking to connect legacy Private Branch

Exchange (PBX) via IP as well as for direct user

connectivity. Moreover VoIP is offered by public

service providers for residential customers.

Critical requirements on information security

cannot be satisfied by relying on “trust by wire secu-

rity” as done within traditional telephone network

architectures. The distributed and heterogeneous

VoIP system architecture itself enables attacks

against integrity and confidentiality of data commu-

nicated over the packet network. Inevitable threats to

the availability of the involved components are evi-

dent. Therefore comprehensive and consistent secu-

rity architectures are necessary prerequisites for

running VoIP communication systems based on

bundled multimedia standards. Note that in VoIP

scenarios signaling and media may traverse different

communication path and thus pose another challenge

to the overall security approach.

VoIP communication protocols and associated

security is currently being standardized mainly in

four standardization organizations. While the IETF

(Internet Engineering Task Force) and ITU-T (Inter-

national Telecommunication Union) define proto-

cols for VoIP like SIP, SRTP (IETF), and H.323

(ITU-T) as well as surrounding protocols, ETSI and

3GPP (Third generation Partnership Project) define

the architecture for NGN (Next Generation Net-

work) utilizing these protocols.

Typical threats to information security in general

and to VoIP in specific are eavesdropping or wire-

tapping, misuse of service (e.g., through masquerad-

ing), and manipulation.

An overview about information security mecha-

nisms in the commonly used signaling and media

protocols is provided as well as recently defined

security extensions to cover further use cases. It will

be shown that security mechanisms are already in-

corporated into the main VoIP protocols covering a

wide extend of known vulnerabilities.

Challenges for further security related work are

misuse of the multimedia protocol’s functionality for

SPIT (SPAM over Internet Telephony), Denial of

Service attacks (DoS). Moreover, besides basic call

more advanced features are going to be supported in

communication scenarios leading to further security

requirements to be met.

2 BASIC SCENARIOS AND

DEPLOYMENTS

VoIP is gaining more momentum and will be offered

in enterprises and public carriers for business and

183

Fries S. (2006).

SECURITY CONSIDERATIONS IN CURRENT VOIP PROTOCOLS.

In Proceedings of the International Conference on Security and Cryptography, pages 183-191

DOI: 10.5220/0002098601830191

 SciTePress

also personal use. The deployment of VoIP can be

done using different approaches providing also a

possible migration strategy.

A first step for introducing VoIP services is often

the trunking of voice connections between different

PBX’s via packet based networks as shown in

Figure 1. This option does not require the use of IP

enabled clients. Thus, VoIP can be introduced trans-

parent to the end user.

A next step in the deployment is consequently

the introduction of VoIP enabled networks in the

source and/or the target domain, including the ap-

propriate endpoints. These endpoints are able to

communicate completely over the packet based

network, while gateways ensure the connectivity to

legacy PBX systems.

IP Network

PSTN / PBX

Media

Gateway

H.323 / SIP

RTP

H.323 / SIP

RTP

Media

Gateway

PSTN / PBX

IP Network

PSTN / PBX

Media

Gateway

H.323 / SIP

RTP

H.323 / SIP

RTP

Media

Gateway

PSTN / PBX

Figure 1: VoIP Trunking.

A general scenario for VoIP is depicted in Figure

2 as an example for larger enterprises or for carrier

deployments. In these environments the media data

pose a high load on the gateways, when offering

connections to the Public Switched Telephone Net-

work (PSTN). Therefore multiple media gateways

can be coordinated by a single gateway controller.

The support for multiple gateways, targeting a

higher availability rate for connections to the PSTN

as well as cost reduction through the use of a single

controller for multiple gateways, will be discussed

with focus on the security of the supporting proto-

cols in section 5.3.

For smaller enterprises or home offices the me-

dia gateways and the media gateway controller col-

lapse to a single device, eliminating also the need for

additional gateway control protocols.

IP Network

PSTN

Media Gateway

Control Signaling

Megaco/H.248

or MGCP

Media

Gateway

RTP

SIP or H.323

RTP

SIP or H.323

RTP

SIP or H.323

RTP

SIP Proxy OR

H.323 Gatekeeper

AND Media

Gateway Controller

Client

IP Network

PSTN

Media Gateway

Control Signaling

Megaco/H.248

or MGCP

Media

Gateway

RTP

SIP or H.323

RTP

SIP or H.323

RTP

SIP or H.323

RTP

SIP Proxy OR

H.323 Gatekeeper

AND Media

Gateway Controller

Client

Figure 2: Multiple Gateway Support.

The final stage of VoIP would be a pure packet

based voice communication network and may be

seen as subset of the scenario depicted above. Be-

cause of this and as PSTN-based telephony will exist

in parallel to VoIP for quite some years, this sce-

nario is not further considered here.

3 TYPICAL VULNERABILITIES

AND THREATS

A threat to information security can be defined as

attempt at unauthorized access to an object by an

attacker.

Besides the general threats for packet-based IP

networks, within VoIP there are some dedicated

threat targets:

− Identity: Attackers may spoof the identities of

service subscribers to misuse services and pro-

duce toll fraud. They may also spoof server iden-

tities to get access to user related information

(one form of spoofing server identities is com-

monly known as phishing).

− Privacy: Eavesdropping or wiretapping of inse-

cure communication of signaling and/or media

connections may lead to loss of sensitive infor-

mation. Examples are PINs or passwords trans-

mitted over the signaling channel or (spoken)

personal information transmitted over the media

channel.

− Availability: Voice or multimedia services are

susceptible to Denial of Service attacks, call hi-

jacking or call disruption. As multimedia-

services are real-time services, the importance of

this property increases. Also, if VoIP is used as a

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

184

complete substitution for PSTN based telephony,

emergency call handling needs to be provided as

it will be required by regulation.

All of these properties are crucial for the general

acceptance of VoIP in business and personal com-

munication. Typical resulting security requirements

are depicted next.

4 SECURITY REQUIREMENTS

As VoIP is transmitted in (former) data networks,

similar security requirements as known for other

services in such a network apply. These are in the

first place:

− Authentication: The property that the claimed

identity of an entity is correct.

− Authorization: The process of giving someone

permission to do or have something.

− Integrity: The property that information has not

been altered in an unauthorized manner.

− Confidentiality: The property that information is

not made available or disclosed to unauthorized

individuals, entities or processes.

Additional challenges for VoIP security are

given through the different communication path for

signaling and media on one hand. Especially the

dynamic port assignment used for the media connec-

tions needs to cope with existing security infrastruc-

ture, like NAT devices and Firewalls.

On the other hand media security or, to be more

precise, the key management for the media security

is crucial (cf. also section 6.3). Here more complex

communication scenarios than simple point-to-point

connections need to be supported. In VoIP these

scenarios comprise the support for early media, i.e.,

a call initiator will receive media data prior to re-

ceiving an answer on the signaling path. Another

example is the forking of calls to reach different

endpoints simultaneously. These endpoints may

belong to the same user or form for instance a work-

ing group (commonly known is the ‘group pickup

feature’). Especially in the latter case user authenti-

cation and identity provision is required and may

pose potential obstacles.

5 VOIP SIGNALING

PROTOCOLS

Currently there exist several protocols for VoIP,

some of them are competitive, e.g., SIP and H.323,

and some are complementary, e.g., SIP and MGCP.

The following subsections comprise the discussion

of security focused on state of the art description of

the signaling protocols SIP (Rosenberg et al, 2002),

H.323 (ITU-T, 2003), Megaco/H.248 (Green, Ra-

malho and Rosen, 2000), and MGCP (Arango et al,

1999). Note, that the first two protocols provide

inherent security means, while the others mainly rely

on IPSec.

Common analyses show that the number of SIP

deployments increases more compared to H.323.

IPSec in general is applicable for UDP, TCP and

SCTP based signaling and may be used to provide

authentication, integrity and confidentiality for the

transmitted data. It supports end-to-end as well as

hop-by-hop scenarios. Thus, it may be used to pro-

vide security functions for all of the above protocols.

Nevertheless, it may not be applicable straight for-

ward, as it is often not considered by the signaling

standard itself and may not provide for advanced

communication scenarios. Moreover, due to the

message overhead of IPSec it may not be easily

applicable for real-time media communication.

Therefore alternative approaches have been taken.

5.1 SIP

The Session Initiation Protocol is specified by the

IETF in RFC3261 SIP (Rosenberg et al, 2002). It

enables the initiation and control of communication

sessions, which may be VoIP or complete multime-

dia sessions. The general architecture is shown in

Figure 2, were the server is called SIP proxy or redi-

rect server. The signaling of control information is

done using SIP, while media is sent using RTP.

SIP is a text–based Internet protocol similar to

protocols like Hypertext Transfer Protocol (HTTP)

and Simple Mail Transport Protocol (SMTP) in

contrast to other protocols like H.323 basing on the

Abstract Syntax Notation (ASN.1). ASN.1 requires

additional encoding and decoding operations. Never-

theless, if security using Secure Multipurpose Inter-

net Mail Extensions (S/MIME) is provided, ASN.1

becomes an issue also for SIP. SIP is independent of

the transport layer (supports User Datagram Protocol

(UDP), Transport Control Protocol (TCP) and

Stream Control Transmission Protocol (SCTP)) and

has been designed to be not restricted for Voice over

IP.

SIP already considers security and provides

measures for the most common scenarios. As SIP is

flexible with regard to extending the protocol, sev-

eral security enhancements have already been stan-

dardized. Furthermore, as new scenarios arise, new

SECURITY CONSIDERATIONS IN CURRENT VOIP PROTOCOLS

185

security extensions are being proposed. This is also

depicted in section 5.1.2.

Recent discussions also comprise the usage of

SIP to realize peer-to-peer VoIP systems. This will

pose new security requirements to VoIP. Main work

for security can be seen here in the area of distrib-

uted identities, prevention of spoofing, and denial of

service.

5.1.1 SIP Inherent Security Features

As stated above RFC3261 provides several security

features, which are depicted next.

Signalling data authentication using HTTP Digest

Authentication

SIP digest authentication is based on the HTTP

digest authentication defined in RFC2617 describing

a simple challenge-response paradigm. The remote

end is challenged using a nonce value. A valid re-

sponse contains a checksum (by default, the MD5

checksum) of the user name, the password, the given

nonce value, the HTTP method, and the requested

URI (Uniform Resource Identifier). In this way, the

password is never sent in the clear. Nevertheless,

there are some deficiencies in the usage of the HTTP

Digest scheme, as it does not provide complete mes-

sage integrity and may not be applied to all mes-

sages. Here TLS kicks in, which can be used to

enhance the signaling protection.

Approaches for protecting the signaling data

using TLS

RFC3261 mandates the support of TLS for SIP

server components (proxies, redirect servers, and

registrars) to protect SIP signaling. Using TLS for

User Agents (UAs) is recommended. TLS protects

SIP signaling messages against loss of integrity,

confidentiality and against replay. It provides inte-

grated key-management with mutual authentication.

TLS is applicable hop-by-hop between UAs and

proxies or between proxies. The SIP-Secure (SIPS)

scheme defined in RFC3261 requires the usage of

TLS to protect the signaling until the last proxy in

the call flow. Drafts are currently being discussed

addressing the deficiency regarding the last hop

usage of TLS (see section 5.1.2). TLS is usually

applied in a hop-to-hop fashion. Note that the calling

client does not get a confirmation about the usage of

TLS till the final recipient. It merely has to trust the

proxies acting according to the standard. The draw-

back of TLS in SIP scenarios is the requirement of a

reliable transport stack (TCP-based SIP signaling).

The recent development of Datagram-TLS (DTLS)

may provide for using a TLS-like protection also for

UDP based signaling. RFC3261 mandates the sup-

port of a dedicated TLS crypto scheme, which en-

sures interoperability. Other schemes may be negoti-

ated as part of the TLS handshake.

S/MIME to protect SIP message body data in an

end-to-end fashion

RFC3261 recommends the IETF defined stan-

dard S/MIME (RFC3850 and RFC3851) to be used

for end-to-end protection of signaling message pay-

loads. S/MIME within SIP supports the following

security services:

− Authentication and Integrity Protection of Sig-

naling Data

− Confidentiality of Signalling Data

Note that S/MIME is not widely used in current

SIP deployments and therefore not further discussed.

5.1.2 SIP Security Extensions

Meanwhile more complex SIP communication sce-

narios have been worked out, requiring additional

Request For Comments (RFCs) and new drafts en-

suring authentication and integrity and also confi-

dentiality. Identity is one of the intensively dis-

cussed topics within the SIP community. This can be

seen on the variety of documents concerning iden-

tity.

In the following an overview about a subset of

the most interesting security extensions is given.

These extensions solve different problems identified

in SIP communication scenarios.

SIP Authenticated Identity Body

SIP Authenticated Identity Body (AIB) defines a

generic SIP authentication token. It is provided by

adding an S/MIME body to a SIP request or re-

sponse in order to provide reference integrity over

its headers. The AIB is a digitally signed SIP mes-

sage or message fragment. This approach has been

standardized as RFC3893.

Enhancements for the Authenticated Identity

Management in SIP

The security options of RFC3261 utilize asym-

metric security in terms of certificates and corre-

sponding private keys. The distribution of these

credentials is often complex and limited to a dedi-

cated domain. Certificates can be used to provide

means for identity management, but this may not be

uniquely defined. An example can be drawn by two

different administrative domains with domain-

specific PKIs. The current draft (Peterson and

Jennings, WiP) addresses this limitation by defining

an authentication service providing assertions for the

user identity (Address of Record) transmitted in the

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

186

header of SIP requests. This authentication service is

responsible for a dedicated domain.

Certificate Management Service for SIP

As stated before, certificate distribution is often

cumbersome and a global Public Key Infrastructure

(PKI) does not exist so far. Several security services

for SIP relay on certificates, so their distribution

becomes a crucial part. The draft (Jennings and

Peterson, WiP) describes a solution using a certifi-

cate server to provide certificates and even complete

user credentials using a Simple Authentication and

Security Layer (SASL) like approach. Users have

the option to store their complete credentials or only

the certificate over a secure connection on a central

server. This may be useful, when users are in need to

transmit credentials between different devices.

Connection Reuse / Outbound Connections

SIP defines the usage of TLS to protect the sig-

naling. But it requires only server components to

support mutual authentication. This leads to the

problem that clients without a TLS certificate cannot

receive inbound calls over TLS. This is due to the

fact that SIP communication is done over distinct

ports for inbound and outbound traffic. Furthermore,

an endpoint without a certificate TLS may not be run

in server-mode. To handle this deficiency two drafts

(Jennings and Hawrylyshen, WiP) and (Mahy, WiP)

describe the possibility of reusing already estab-

lished TLS connection, which were initiated by the

client. The basic idea is the provision of a flow iden-

tifier for the different streams within an established

session to identify inbound and outbound traffic.

5.2 H.323

H.323 (ITU-T, 2003) is an umbrella recommenda-

tion defined by the ITU-T (International Telecom-

munication Union). H.323 addresses call control,

multimedia management, and bandwidth manage-

ment as well as interfaces between LANs and other

networks. It includes point-to-point and multipoint

conferences. The first version has been defined in

1996 and has been improved consistently. Security

features have become part of the standard.

The general architecture is similar to SIP and can

also be depicted using Figure 2, were the server is

called H.323 gatekeeper. The signaling of control

information is done using H.225, while media is sent

using RTP.

The call establishment can be performed in vari-

ous ways, as there are gatekeeper routed calls, direct

routed calls with gatekeeper (for address resolution)

and plain direct routed calls.

The security functionality is defined within

H.235 (ITU-T, 2005). H.235 is splitted in 9 sub-

groups, describing so-called profiles for security in

H.323.

5.2.3 H.323 Security Profiles

The security profiles may be distinguished as pro-

files for signaling integrity and authentication and

for media security. They are related to the call mod-

els used in H.323. Note that the former H.235 an-

nexes have been reorganized in a new form

(H.235.x) recently.

− H.235.0 provides the framework of the subse-

quent H.235 standards within H.323.

− H.235.1 provides signaling integrity and authen-

tication using mutually shared secrets and keyed

hashes (HMAC-SHA1-96) in gatekeeper-routed

scenarios. This profile is widely implemented in

available H.323 solutions.

− H.235.2 provides signaling integrity and authen-

tication using digital signatures on every mes-

sage in gatekeeper-routed scenarios. Since signa-

ture generation and verification is costly in terms

of performance, this profile may not gain mo-

mentum.

− H.235.3 is a hybrid approach using both, H.235.1

and H.235.2. During the first handshake a shared

secret establishment is performed, protected by

digital signatures. Afterwards keyed hashes are

used for integrity protection, based on the estab-

lished shared secret.

− H.235.4 is the adaptation of H.235.1 for direct

routed call scenarios with gatekeeper, were the

gatekeeper provides the key material for securing

the direct routed call.

− H.235.5 specifies a framework for secure mutual

authentication during the registration and admis-

sion phase using weak shared secrets in combi-

nation with Diffie-Hellman key agreement for

stronger authentication during call signaling. Ex-

tensions to the framework to permit simultaneous

negotiation of TLS parameters for protection of a

subsequent call signaling channel are also pro-

vided.

− H.235.6 describes the voice encryption profile.

This profile relies on certain security services as

part of the call signaling and connection setup

procedures; e.g., the Diffie-Hellman key agree-

ment and other key management functions and is

not compatible to SRTP.

− H.235.7 can be seen as evolvement of H.235.6 as

it provides the framework for providing key ma-

SECURITY CONSIDERATIONS IN CURRENT VOIP PROTOCOLS

187

terial for media encryption based on MIKEY and

SRTP within H.235.

− H.235.8 describes another approach for key

management for SRTP as ‘Key Exchange for

SRTP using secure signaling channels’. This is a

sdescriptions-like (cf. section 6.3.2) approach

were all parameter necessary for voice encryp-

tion are sent in-band protected by underlying se-

curity (e.g., like TLS) or by using Cryptographic

Message Syntax (CMS).

− H.235.9 depicts the most recent extension of

H.235; the security gateway support for H.323.

The document defines a method for the discov-

ery of security gateways in the signaling path be-

tween communicating H.323 entities, and for

sharing of security information between a gate-

keeper and a security gateway in order to pre-

serve signaling integrity and privacy when cross-

ing network boundaries.

H.235 security features are defined to complete

H.323 scenarios. Additionally, the interworking with

security features of other multimedia protocol suites,

e.g., SIP, is considered. An example is the key man-

agement and media data encryption using H.235.7

and H.235.8.

5.3 Gateway Decomposition

Gateway decomposition describes the separation of

signaling and media functionality. The general goal

of gateway decomposition is a cost reduction

through the use of only one media gateway control-

ler responsible for several media gateways. The

media gateway controller connects to common mul-

timedia signaling protocols like SIP or H.323, de-

scribed above and controls the media gateways via a

trivial protocol. The general architecture approach is

shown in Figure 2.

There are two commonly used protocols within

the context of gateway decomposition – Megaco

(Green, Ramalho and Rosen, 2000) and MGCP

(Arango et al, 1999). Megaco/H.248 has basically

the same architecture as MGCP. Also the commands

are similar. However, the protocol models are quite

different.

Generally, these gateway control protocols pro-

vide complementary functionality and architectural

components to plain SIP or H.323 architectures.

5.3.1 Megaco

In June 1999 IETF Megaco Working Group (WG)

and ITU-T provided a unified document describing a

standard protocol for interfacing between Media

Gateway Controllers (MGCs) and Media Gateways

(MGs) Megaco/H.248. It is expected to win wide

industry acceptance as the official standard for de-

composed gateway architectures.

RFC2805 recommends security mechanisms that

may be in underlying transport mechanisms, such as

IPSec. H.248 goes even a step further by requiring

that IPSec shall be implemented, where the underly-

ing operating system and the transport network sup-

port IPsec. Implementations of the protocol using

IPv4 shall implement the interim AH scheme.

The interim AH scheme is the usage of an op-

tional AH header, which is defined in the H.248

protocol header. The header fields are exactly those

of the SPI, SEQUENCE NUMBER and DATA

fields as defined in RFC4302. The semantics of the

header fields are compliant with the "transport

mode" of RFC4302, except for the calculation of the

Integrity Check Value. The interim Authentication

Header (AH) scheme does not provide protection

against eavesdropping and replay attacks (the se-

quence number in the AH may overrun when using

manual key management since re-keying is not pos-

sible).

5.3.2 MGCP

MGCP is currently being maintained by Packet-

Cable

and the Softswitch Consortium

. In Octo-

ber 1999, MGCP was finally converted into an in-

formational RFC2705.

Regarding security, there are no mechanisms de-

signed into the MGCP protocol itself. The informa-

tional RFC2705 (Arango et al, 1999) refers to the

use of IPSec (either AH or Encapsulated Security

Payload (ESP)) to protect MGCP messages. Without

this protection an adversary could setup unauthor-

ized calls or interfere with ongoing authorized calls.

Beside the usage of IPSec, MGCP allows the call

agent to provide gateways with session keys that can

be used to encrypt the payload of the Real-time

Transport Protocol (RTP), protecting against eaves-

dropping. To achieve this RTP encryption, described

in RFC3550 (Schulzrinne, 2003) may be applied.

Session keys can be transferred between the call

agent and the gateway by using SDP Handley and

Jacobson, 1998) either directly or using dedicated

key management extensions.

6 MEDIA DATA SECURITY

The signalling protocols described above do not

consider the encryption of media data directly. Nev-

ertheless, they allow the negotiation of security

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

188

features and also the key management for the secu-

rity associations of the media channels.

Real-time media data in VoIP environments is

usually transmitted using RTP. For RTP basically

two approaches for security provisioning exist,

which are discussed in the following.

6.1 RTP/RTCP

RFC3550 defines the RTP protocol as well as the

associated Real Time Control Protocol (RTCP).

Using the optional RTP encryption as defined in

RFC3550 provides for confidentiality for media data

using the Data Encryption Standard (DES) as default

method. The functionality is limited as the following

issues are not considered in the RTP standard:

− key management

− authentication and message integrity (not feasi-

ble without a key management infrastructure)

− replay protection

Because of these points, the usage of this option

is not widely deployed.

6.2 SRTP/SRTCP

The RTP standard provides the flexibility to adapt to

application specific requirements with the option to

define profiles in companion documents. SRTP

(Baugher et al, 2004) has been recently defined as

RTP profile and addresses the limitations. This pro-

file provides confidentiality using the Advanced

Encryption Standard (AES, the successor of the

DES), message authentication (using keyed hashes)

and replay protection to the RTP/RTCP traffic.

SRTP does not define an own key management

and relies on solutions like MIKEY or sdescriptions

(cf. section 6.3). The key management messages

have to be transported by the signaling protocol.

For SDP based protocols like SIP or MGCP the

key transport can be transported as part of SDP it-

self, while for H.323 extensions to the base protocol

are defined through H.235.7 and H.235.8 as de-

scribed above.

6.3 Key Management

In contrast to common data applications, the key

management for negotiating the VoIP media security

has to cope with several additional requirements, as

there the real-time conditions, support of advanced

communication scenarios like forking, retargeting

and also conferencing. Moreover, due to the nature

of VoIP to separate signaling and media traffic, the

key management may be done along the path of the

signaling data, the media data, or combined.

Currently there is a broad discussion about the

key management for SRTP using SIP within the

IETF as meanwhile 13 different approaches exist.

They utilize different cryptographic techniques like

pre-shared keys, Diffie-Hellman key agreement,

digital signatures, or asymmetric encryption (cf.

(Audet and Wing, WiP)). Due to the different

mechanisms used, the approaches are not interoper-

able. Moreover, none of the current approaches

provides a solution for all of the scenarios stated

above.

In the following subsection two promising key

management approaches out of the 13 are depicted

in more detail. Both belong to the cluster of signal-

ing path key management approaches and have been

deployed already. Examples for media path key

management are given through ZRTP (cf.

(Zimmermann, WiP)) and DTLS usage (cf.

(McGrew and Rescorla, WiP)).

6.3.1 Multimedia Internet Keying

MIKEY (Multimedia Internet Keying) has been

defined in the IETF within RFC3830 (Akko, 2004).

It defines an authentication and key management

framework that can be used for real-time applica-

tions (both for peer-to-peer communication and

group communication). In particular, RFC3830 is

defined in a way to support SRTP in the first place

but is open to enhancements to be used for other

purposes too. MIKEY has been designed to meet the

requirements of initiation of secure multimedia ses-

sions. Such requirements are for instance the estab-

lishment of the security parameters for the multime-

dia protocol within one round trip.

Another requirement is the provision of end-to-

end keying material, and also independence from

any specific security functionality of the underlying

transport layers.

MIKEY defines several options for the user au-

thentication and negotiation of the master keys with

a maximum of a complete round trip as there are:

− Symmetric key distribution (based on pre-shared

keys and keyed hashes), which may proceed with

a single message.

− Asymmetric key distribution (based on asymmet-

ric encryption) may proceed with a single mes-

sage.

− Diffie Hellman key agreement protected by digi-

tal signatures (complete roundtrip)

Unprotected key distribution, i.e., without au-

thentication, integrity, or encryption, is also possi-

SECURITY CONSIDERATIONS IN CURRENT VOIP PROTOCOLS

189

ble, but not recommended without any underlying

security like TLS or similar. This use case is compa-

rable with the sdescription approach described be-

low.

Two MIKEY enhancements exist as drafts,

which are likely to advance to a RFC soon.

− Diffie Hellman key agreement protected by

symmetric pre-shared keys and keyed hashes

− Asymmetric (encrypted) key distribution with in-

band certificate provision

The default and mandatory key transport encryp-

tion is the AES in counter mode, where MIKEY

references RFC3711. MIKEY uses a 160-bit authen-

tication tag, generated by HMAC with SHA-1 as

mandatory algorithm described in the associated

RFC2104. Also mandatory, when asymmetric

mechanisms are used, is the support of X.509v3

certificates for public key encryption and digital

signatures.

Recently the usage of elliptic curves has been

proposed targeting performance saving and enabling

the use of shorter cryptographic key material by

keeping the same level of security compared to the

currently used RSA.

6.3.2 Security Descriptions

Besides MIKEY a second key management for

SRTP has been proposed in the IETF, which utilizes

the plain Session Description Protocol (SDP). The

approach is based on the offer answer model of SDP

and transmits all necessary SRTP parameter in a

new attribute field and is called sdescriptions (cf.

(Flemming and Baugher, WiP)).

The protection of this field is left to SIP itself

(applying S/MIME in an end-to-end fashion) or may

be done using TLS (in a hop-to-hop fashion) or even

IPSec. It therefore nicely integrates with SIP. For

other signaling protocols like H.323 there exist simi-

lar approaches (through H.235.8). Because of the

signaling protocol dependent approach, this solution

lacks the support of end-to-end security.

7 CONCLUSION

As shown in this paper, current multimedia proto-

cols already consider security to certain extends.

SIP and H.323 are here the most advanced proto-

cols, as they provide inherent security measures for

user authentication and message integrity. Confiden-

tiality can be achieved by additional measures like

S/MIME or underlying security protocols TLS or

IPSec. Both signaling protocols also provide options

to transport a key management for SRTP. Several

key management approaches have been proposed

leading to the requirement for profiles to ensure easy

(inter)operation.

SIP and H.323 suffer from dynamic port signal-

ing as part of the protocol payload, which may lead

to problems with widely deployed NAT devices,

when message integrity or confidentiality is desired.

Within the IETF efforts have been spent to cope

with this problem by providing a methodology for

Interactive Connectivity Establishment (ICE,

(Rosenberg, WiP)).

Security for gateway control protocols is mainly

provided by using IPSec as underlying security

protocol. Here the communication association is

merely between the controller and the associated

gateways. Thus, the signaling scenarios are rather

simple compared to SIP and H.323.

As the scenarios, in which VoIP is about to be

deployed, are getting more complex through the

integration of already available features of the leg-

acy telephone system, new security requirements

arise. An example is the handling of security proper-

ties like user authentication or media session confi-

dentiality in case of call transfer. This is especially

becoming interesting in scenarios were the partici-

pants of a call cannot rely on the same security in-

frastructure. Here a global PKI solution could sup-

port user authentication. As this is not available right

now, alternative approaches are necessary.

Potential obstacles for VoIP usage may arise

through the possibility of misusing the infrastructure

resulting in Denial of Service. SPIT will pose an-

other potential obstacle. As seen for today’s email

communication SPAM poses a severe problem for

communication. To counter similar threats in VoIP

certain measures have to be taken and are already

being discussed.

Further challenges are given through the user’s

request for interoperability, whereby this relates to

several facets, like the implementation of a standard

through different vendors and also proprietary en-

hancements. Moreover other solutions are available,

which are not standardized so far. While the first

point may be covered by regular interoperability

tests, the second leads to a subset of common func-

tionality, which ensures interworking. For SIP the

definition of this common set of functions is done in

the SIP Forum. A prominent example for the third

point is Skype, providing security of signaling and

media traffic in a proprietary way, not interoperable

to SIP or H.323 based clients. Thus security inter-

working in an end-to-end fashion may not be possi-

ble.

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

190

Last but not least, security functions provided by

signaling and media protocols are only one part of

the multimedia puzzle. There is more work to be

done in defining the suitable system architecture and

deploying multimedia systems in a secure way. Most

important, multimedia systems have to be designed

into already existing networks under consideration

of security, availability, quality of service, and also

legal terms. This is also outlined in (Kuhn, Walsh

and Fries, 2005). Especially for emergency services

appropriate measures have to be taken to meet the

balance between security and availability.

ACKNOWLEDGEMENTS

The author would like to thank Wolfgang Klasen

and Michael Montag for their valuable review com-

ments and discussions.

REFERENCES

Rosenberg, J., Schulzrinne, H., Camarillo, G., Johnston,

A., Peterson, J., Sparks, R., Handley, M. and Schooler,

E., 2002, RFC3261: SIP: Session Initiation Protocol

ITU-T, 2003, H.323v5: Packet-based multimedia commu-

nications systems

Rosenberg, J., Work in Progress, ICE: A Methodology for

Network Address Translator (NAT) Traversal for Of-

fer/Answer Protocols,

Greene, N., Ramalho, M. and Rosen, B., 2000, RFC2805:

Media Gateway Control Protocol Architecture and

Requirement,

Arango, M., Dugan, A., Elliott, I., Huitema, C. and

Pickett, S., 1999, RFC2705: Media Gateway Control

Protocol Version 1.0

Handley, M. and Jacobson, V., 1998, RFC2327: SDP:

Session Description Protocol

Schulzrinne, H., Casner, S., Frederick, R. and Jacobson,

V., 2003, RFC3550: RTP: A Transport Protocol for

Real-Time Applications

Baugher, M., McGrew, D., Naslund, M., Carrara, E. and

Norrman, K., 2004, RFC3711: The Secure Real-time

Transport Protocol

Audet, F. and Wing, D., Work in Progress, Evaluation of

SRTP Keying with SIP

Arkko, J., Carrara, E., Lindholm, F., Naslund, M. and

Norrman, K., 2004, RFC3830: MIKEY: Multimedia

Internet KEYing

ITU-T, 2005, H.235.0: Security framework for H-series

Arkko, J., Carrara, E., Lindholm, F., Naslund, M. and

Norrman, K., Work in Progress, Key Management Ex-

tensions for Session Description Protocol (SDP) and

Real Time Streaming Protocol (RTSP)

Peterson, J. and Jennings, C., Work in Progress, En-

hancements for Authenticated Identity Management in

the Session Initiation Protocol

Jennings, C. and Peterson, J., Work in Progress, Certifi-

cate Management Service for The Session Initiation

Protocol,

Jennings, C. and Hawrylyshen, A., Work in Progress, SIP

Conventions for UAs with Outbound Only Connection,

Mahy, R., Work in Progress, Connection Reuse in the

Session Initiation Protocol (SIP)

Flemming, A., Baugher, M. and Wing, D., Work in Pro-

gress, Session Description Protocol Security Descrip-

tions for Media Streams

Zimmermann, P., Work in Progress, ZRTP: Extensions to

RTP for Diffie-Hellman Key Agreement for SRTP

McGrew, D. and Rescorla, E., Work in Progress, Data-

gram Transport Layer Security Extension to Establish

Keys for Secure Real-time Transport Protocol

Kuhn, D.R., Walsh, T.J. and Fries, S., 2005, Security

Considerations for Voice over IP Systems, SP800-58,

US NIST

SECURITY CONSIDERATIONS IN CURRENT VOIP PROTOCOLS

191
