AN ESTIMATION OF DISTRIBUTION ALGORITHM FOR THE

CHANNEL ASSIGNMENT PROBLEM

Jayrani Cheeneebash

Department of Mathematics, University of Mauritius, Reduit, Mauritius

Harry C. S. Rughooputh

Department of Electrical and Electronic Engineering, University of Mauritius, Reduit, Mauritius

Keywords: Channel Assignment problem, Estimation of Distribution Algorithm.

Abstract: The channel assignment problem in cellular radio networks is known to belong to the class of NP-complete

optimisation problems. In this paper we present a new algorithm to solve the Channel Assignment Problem

using Estimation of Distribution Algorithm. The convergence rate of this new method is shown to be very

much faster than other methods such as simulated annealing, neural networks and genetic algorithm.

1 INTRODUCTION

During the recent years, it has been observed that the

improved portability and widespread of

communication systems has accentuated the demand

for mobile users. However, since the number of

usable frequencies, which are necessary for the

communication between mobile users and the base

stations of cellular radio networks, is very limited,

an efficient use of the frequency spectrum or

channels is crucial to meet the increasing demands.

Therefore while assigning the frequencies to

different base stations, it is desirable to reuse the

same frequency as much as possible. On the other

hand, it is important to avoid possible interferences

between different mobile users, at the same time, the

number of frequencies assigned to each base station

must be chosen large enough to satisfy the given

demand in the corresponding cell. Regarding the

above requirements, one can formulate the

frequency assignment problem as a discrete

optimisation problem.

The channel assignment problem (CAP) is

defined as an NP-complete problem. The channel

assignment must fulfil the following three

constraints:(Sivaranjan, McElliece and Ketchum,

1986)

1. The Co-Channel Constraint (CCC): The same

channel cannot be assigned to a pair of cells

within a specified distance simultaneously.

2. The Adjacent Channel Constraint (ACC):

Adjacent Channels cannot be assigned to cells

simultaneously.

3. The Co-site Constraint (CSC): The distance by

an nn

symmetric matrix called the

compatibility matrix

between any pair of

channels used in the same cell must be larger

than a specified distance.

In 1982, Gamst and Rave defined the general form

of the channel assignment problem in an arbitrary

inhomogeneous cellular radio network (Gamst,

1982). In their definition, compatibility constraints

in an n-cell network are described

][

cC =

. Each

non-diagonal element

c in C represents the

minimum separation distance in the frequency

domain between a frequency assigned to cell i and a

frequency to cell j. The Co-Channel constraint is

represented by

c , the adjacent channel

constraint is represented by

c and 0

indicates that cells i and j are allowed to use the

same frequency. Each diagonal element

c in C

represents the minimum separation distance between

any two frequencies assigned to cell i, which is the

co-site constraint, where

1≥

c is always satisfied.

211

Cheeneebash J. and C. S. Rughooputh H. (2006).

AN ESTIMATION OF DISTRIBUTION ALGORITHM FOR THE CHANNEL ASSIGNMENT PROBLEM.

In Proceedings of the International Conference on Wireless Information Networks and Systems, pages 211-214

 SciTePress

The channel requirements for each cell in an n-cell

network are described by an n element vector which

is called the demand vector D. Each element

d in

D represents the number of frequencies to be

assigned to cell i. When f

indicates the k

frequency assigned to cell i, the compatibility

constraints are represented by:

ijjlik

cff ≥− for ,,,1, nji …=

k = 1,…,d

, l = 1,…,d

except for i = j, k = l.

Many researchers have investigated the channel

assignment problem using non-iterative algorithms

(Gamst and Rave, 1982), (Sivaranjan, McElliece and

Ketchum1981) and iterative algorithms (Funabiki

and Takefyi, 1992), (Kunz, 1991). Neural Networks

Algorithms and Genetic Algorithms are among the

iterative algorithms in which an energy or cost

function representing frequency separation

constraints and channel demand is formulated and is

then minimised. Unfortunately, the minimisation of

the cost function is quite a difficult problem because

of the danger of getting stuck in local minima

constitutes a major problem. A much more powerful

approach to cope with the problem of local minima

has been considered in (Beckmann and Killat, 1999),

(Fu, Pan and Bourgeois, 2003).

This paper is organised as follows: section 2

gives a brief exposé on Estimation of Distribution

Algorithms and section 3 presents the new method

that we propose in this paper. In section 4 we show

the performance of our algorithms in solving some

benchmark problems and finally we conclude in

section 5.

2 SEARCH AND OPTIMISATION

ALGORITHMS

Genetic Algorithm (GA) depends to a large extent

on associated parameters like operators and

probabilities of crossing and mutation, size of

population, rate of generational reproduction, and

the number of generations. The researcher requires

experience in the resolution and use of those

algorithms in order to choose suitable values for

these parameters. All these reasons have motivated

the creation of a new class of evolutionary

algorithms classified under the name of Estimation

of Distribution Algorithms (EDAs) (Larranaga and

Lozano, 2002), which attempts to ease the prediction

the movements of the population in the search space

as well as to avoid the need of so many parameters.

EDAs are population based search algorithms based

on probabilistic modelling. The new individuals are

sampled starting from a probability distribution

estimated from the database containing only selected

individuals from the previous generation. The

interrelations between the different variables

representing the individuals are expressed explicitly

through the joint probability, associated with the

individuals selected at each iteration.

Given the population of the

l th generation , P

the

N selected individuals,

P , constitute a data set

N cases of ),...,,(

21 n

XXXX

. Denoting the

joint probability distribution of

)()( xXx

. EDAs estimate )(x

from

P .

The pseudo-code of EDA is as follows (Larranaga

and Lozano, 2002):

←

Generate M individuals (the initial

population) randomly.

Repeat for l =1,2,… until a stopping criteria

is met.

←

−

Select N ≤ M individuals from

1−l

P according to a selection method.

)|()(

Pxx

−

ρρ

←

Estimate the

probability distribution of an individual

being among the selected individuals.

←

Sample M individuals (the new

population from

)(x

In the above pseudo-code of EDA there are

four main steps:

(i)

The first population P

of M

individuals is generated, usually by

assuming a uniform distribution (either

discrete or continuous) on each

variable, and evaluating each of the

individuals.

(ii)

A number N (N ≤ M) of individuals are

selected, usually the fittest.

(iii)

Thirdly, the n-dimensional

probabilistic model that better

expresses the interdependencies

between the n variables is induced.

(iv)

The new population of M new

individuals is obtained by simulating the

probability distribution learnt in the

previous step.

Steps (ii), (iii) and (iv) are repeated until a

stopping condition is verified. The most

important step is to find the interdependencies

between the variables (step (iii)), and this is

WINSYS 2006 - INTERNATIONAL CONFERENCE ON WIRELESS INFORMATION NETWORKS AND SYSTEMS

212

done using techniques from probabilistic

graphical models.

3 A NEW APPROACH

From literature review, it is known that call

orderings and minimisation of cost functions have

been used in solving the frequency assignment

problem (Kunz, 1991), (Sivaranjan, McElliece and

Ketchum,1986). It has been noticed that the

advantages of the method using call orderings

correspond to the disadvantages of the cost

minimising approaches and vice-versa. Using the

idea of Beckmann in (Beckmann and Killat, 1999),

we combine the two methods so as to gain their

advantages. We propose to use EDA to solve

combinatorial optimisation problems for the

determination of an optimal satisfying call list

and assign the frequencies using FEA (Beckmann

and Killat, 1999);this assures that in contrast to all

existing cost-minimising methods, we only get legal

frequencies without any interferences. This strategy

derives only channel allocations which do not

violate any of the interference constraints during the

search process which leads to a desirable reduction

of the search space. In our method the main

optimisation work with EDA is done to search for an

optimal frequency assignment.

Figure 1: New Method.

Our method is summarised in Figure 1. It can be

seen that new call lists are generated by the EDA.

The FEA strategy is used to evaluate the quality of

the generated call list L. This means that for each

single call list L we apply the FEA strategy in order

to determine the number of calls without an

allocated frequency; in other words we check how

many calls have been assigned a proper frequency

without violating the interference constraints; such

calls are known as blocked calls denoted by b. A

low value of b then corresponds to a high solution

quality. Then EDA is used to generate new,

hopefully better call lists during the next iteration.

This process is then repeated until the application of

the FEA strategy to a proper call list leads to a

frequency assignment with the desired minimum

frequencies

We now describe how EDA is applied to solve

the channel assignment problem. First, an initial

population of randomised solution vectors are

generated. Each vector is then evaluated using FEA.

The solution vector is then sorted out with respect to

the number of blocked calls and half of the best

solutions is retained. We then estimate the

probability distribution of an individual being

among the selected individuals and then sample a

new population with the same number of individuals

so as to keep the number of individuals in the

population same. The described procedure is

repeated until we get a solution of the desired quality

or the maximum number of iterations is reached.

4 SIMULATION RESULTS

The algorithm described in section 3 has been

applied to the well known benchmark problem, that

is, the 21-cell system shown in Figure 2. This

special example which has been dealt by many

researchers working in the field of frequency

assignment, allows us to compare the results

obtained from the new algorithm with published

results. Different set of problems have been

considered by choosing different demand vectors

D1 and D2 as shown in Table 1 and different

interference conditions summarised in Table 2.

Figure 2: Cells Layout.

Table 1: Frequency Demand Vectors D1 and D2.

D1 8 25 8 8 8 15 18 52 77 28 13 15 31 15 36 57 28 8 10 13 8

D2 5 5 5 8 12 25 30 25 30 40 40 45 20 30 25 15 15 30 20 20 25

AN ESTIMATION OF DISTRIBUTION ALGORITHM FOR THE CHANNEL ASSIGNMENT PROBLEM

213

Table 2: Interference Conditions.

Problem Case 1 2 3 4 5 6 7 8 9 10 11 12

7 7 7 12 12 7 7 7 7 12 12 7

ACC 1 1 2 1 1 2 1 1 2 1 1 2

5 7 7 5 7 5 5 7 7 5 7 5

To evaluate the performance of the new

algorithm, we solve the problem with 50 different

seed values. We choose a maximum of 25 iterations

to stop the algorithm if no solution is obtained. At

each iteration only half of the best solutions are

retained and a new population is sampled. Each

problem case was run 20 times from the different

initial seed values from random generators and the

average generation number is shown in Table 3. To

evaluate the performance of the new algorithm, we

solve the above mentioned problem with 50 different

seed values. Convergence rate is an important factor

to compare the efficiency of a

method which is

shown in Table 3. Problems 3 and 9, converge in

only one generation, this result is comparable to that

obtained in (Beckmann and Killat, 1999). The other

problem cases converge in average of two iterations.

Table 3: Average Number of Generations.

Problem Case Ave Gen Num

1, 5 1.7

2, 4, 6, 7 1.6

3, 9 1

8, 10 1.55

11 1.75

12 1.6

5 CONCLUSION

In this paper we have presented a new method to

solve the frequency assignment problem, which is a

blend of the frequency exhaustive strategy and EDA.

Our results show that EDA can be applied for

solving the channel assignment problem in mobile

cellular environment. EDA has an advantage over

other methods like Neural Networks and Genetic

Algorithms in terms of rapid convergence to the

optimal solution. Hence the new algorithm

presented in this paper seems promising in solving

the CAP problem

REFERENCES

Beckmann, D. and Killat, U., 1999. A new strategy for

the application of genetic algorithms to the channel

assignment problem, IEEE Trans Veh Tech. Vol. 48,

No. 4, , pp. 1262-1269.

Funabiki, N. and Takefyi, Y., 1992. A neural network

parallel algorithm for channel assignment in cellular

radio networks, IEEE Trans Veh Tech. Vol. 41, , pp.

430-437.

Gamst, A. and Rave, W., 1982 On frequency

assignment in mobile automatic telephone systems,

Proceedings of GLOBECOM'82. IEEE., pp. 309-315.

Gamst, A., 1986. Some Lower bounds for a class of

frequency assignment problems, IEEE Trans Veh

Tech. Vol. 35, , pp. 8 – 14.

Kim, J. S., Park, S., Dowd, P. and Nasrabadi, N., 1996.

Channel Assignment in Cellular Radio using Genetic

Algorithm, Wireless Personnal Communications. Vol.

3, , pp. 273-286.

Kunz, D., 1991, Channel Assignment for cellular radio

using neural networks, IEEE Trans Veh Tech. Vol. 40,

, pp. 188-193.

Larranaga, P. and J. A. Lozano., 2002. Estimation of

Distribution Algorithms; A new tool for Evolutionary

Computation, Kluwer Academic.

Sivaranjan, K. N., McElliece, R. J and Ketchum, J. W.,

1986. Channel Assignment in cellular radio.

Proceedings 39

IEEE Veh Tech Conference., pp.

846-850.

Fu, X., Pan, Y. and Bourgeois, A., 2003. A three stage

Heuristic combined Genetic Algorithm Strategy to the

channel assignment problem. Proceedings of the

International Parallel and Distributed Processing

Symposium., pp. 145b.

WINSYS 2006 - INTERNATIONAL CONFERENCE ON WIRELESS INFORMATION NETWORKS AND SYSTEMS

214
