NOTIFICATION SERVICES FOR MOBILE AND WIRELESS
TERMINALS
A Class of Services Appropriate for Mobile Scenarios
Michael Decker, Rebecca Bulander
Institute AIFB, University of Karlsruhe, Englerstr. 11, 76 128 Karlsruhe, Germany
Keywords: Mobile and wireless services, notification services, context-awareness.
Abstract: We introduce the concept of a notification service and show that while simple this class of services is
especially suited for mobile scenarios and many useful mobile services can be considered as notification
services.
1 INTRODUCTION
Many publications in the field of mobile business
and mobile computing deal with platforms or
frameworks for mobile services whereas often the
focus is on architectural considerations or how to
process context information. What is often missing
is an exact description of the class of service
supported by the platform. There are also many
services which are just mobile version of services
known from the conventional internet. Those
services are not always appropriate for mobile
scenarios, e.g. users don’t want to browse web sites
for hours when they use a mobile terminal.
In this article we will introduce the concept of a
notification service (NS). The basic idea is that
because of the technical limitations and the
ergonomic restrictions of mobile terminals along
with the typical habits of usage in mobile scenarios
one cannot expect much more of users than to
perform a short configuration of a service and read
notification message on mobile devices. A clear
description of NS is provided along with examples
that create mobile value and a discussion why this
class of services is very suitable for scenarios with
mobile terminals.
The remainder of this article is organized as
follows: in the second section we introduce the
concept of a NS. We argue why this class of mobile
services is appropriate for mobile scenarios in
chapter three. Examples for mobile services that
could be implemented as NS are listed in section
four, in section six we conclude with a summary and
outlook.
2 NOTIFICATION SERVICES
2.1 Definition
A service is a certain set of functionalities offered by
one or more servers (backend system) to clients; in
the case of mobile (and wireless) services these
clients are mobile terminals (MT) like cellular
phones, PDAs or smartphones and at least the first
leg of the data transmission between clients and
backend systems depends on standards for wireless
data communication like GPRS, WiFi or UTMS.
According to our definition a notification
services (NS) is a service that based on
configuration and context information can send one
or more push-messages to a user’s MT. Push
messages in this sense are messages that the
recipient perceives as not being directly requested
1
(e.g. SMS/MMS, e-Mail, WAP-Push). Context
information (in mobile computing) is information
that is available in explicit form at the runtime of a
service (or application) and deliberately used to
support the user’s interaction with the service (resp.
application), see also Dey (2001). We distinguish
personal context and public context information:
personal context information is information that
1
From the technical perspective a push message might be a pull
messages (explicitly requested) indeed.
151
Decker M. and Bulander R. (2006).
NOTIFICATION SERVICES FOR MOBILE AND WIRELESS TERMINALS - A Class of Services Appropriate for Mobile Scenarios.
In Proceedings of the International Conference on e-Business, pages 151-156
DOI: 10.5220/0001427601510156
Copyright
c
SciTePress
contains person-related data (like current location of
user, his profile); in contrast to public context
information (e.g. time, weather) there are privacy
concerns relating to personal context information.
The semantics of the notification messages and
the configuration data and context information
required depends on the type of the service. We
denote a configured instance of a distinct type of NS
as “order”.
One type of mobile services we could implement
as notification service is “location based
advertising” (Kölmel & Alexakis, 2002): according
to his profile and current position the user receives
advertisement messages on his MT of nearby shops.
We use this example to illustrate the basic principle
of NS: the configuration data is a wish list of
products and services the user is interested in (e.g.
“clothing”, “gastronomy, “entertainment”); the
context information are the profile of the user (e.g.
age, gender) and the current location and time. The
push-messages (notifications) are the messages with
the advertisement.
Figure 1 shows a generic sequence diagram for
NS. Please note that the only mandatory message
exchange is the initial configuration of the service
(bold arrow), all other steps are optional; even the
notification messages are optional (e.g. if the
advertising service cannot find matching offers).
The notifications are not bound to one channel
like SMS or e-Mail for a given order. It is thinkable
that a NS sends messages as MMS to the user under
normal conditions, but if the battery power of the
user’s MT is below a given level (personal context
parameter) SMS are sent instead to help to save
energy; or the service may be configured to send
MMS instead of the usual SMS if the event detected
is considered extraordinary important, e.g. a certain
stock price exceeded or falls below a given value.
There might be even an application-specific push-
channel provided by the mobile client application.
2.2 Technical Details
NS in our sense require a special client application
on the MT and a machine readable description file
(preferred XML-based format) for each service type.
The description file specifies
which attributes the user has to configure,
e.g. formulated using a subset of the
XForms-language (Dubinko , 2003)
which personal context parameters are of
interest (e.g. current location, profile-data,
battery level, …) and have to be filled in
Client-App
on MT
Backend
systems
Configuration data
and/or personal context
information
Push messages
Initial configuration of order along
with personal context information
(only mandatory step)
Update of configuration
Automatic update of
personal context information
time
notification
Update of configuration
Automatic update of
personal context information
notification
termination of order
Legend:
Figure 1: Sequence diagram for the lifespan of a NS instance.
ICE-B 2006 - INTERNATIONAL CONFERENCE ON E-BUSINESS
152
and updated automatically by the client
application.
All information needed for the configuration
must be included in the description file, so no
network interaction between client and server is
necessary during the configuration of the NS.
According to the description file the client
application renders a GUI containing the necessary
widgets (e.g. checkboxes for the wish list in the
advertising example) so the user can configure the
order.
After the reception of a notification the user may
change the configuration of the service, but every
interaction beyond that is out of the responsibility of
the NS, e.g. a notification may include a URL which
points to a WML- or cHTML-document, but the
retrieval of that document is not part of the
notification service itself.
NS as defined above seem to be very limited at
the first glance, but we will show below that there
are a lot of examples for reasonable mobile services
that can be considered as NS. Furthermore they are
appropriate for the technical possibilities of mobile
services. Also this simplicity is beneficial for the
analysis of this class of services, especially with
regard to privacy concerns.
3 SPECIAL SUITABILITY OF NS
FOR SCENARIOS WITH
MOBILE DEVICES
Mobile services have to face several limitations
(Satyanarayanan, 1996), but NS meet these
limitations:
Features of wireless communication: Wireless
data communication is unreliable, (yet) relatively
expensive and of limited bandwidth. One has to
assume connection drop outs when developing a
mobile service and take the variability of the
connection quality into account. Temporary
connection failures should be hidden from the user.
NS meet this requirement: when the user interacts
with the NS (configuration and reading
notifications) no network interaction is required. If
during sending new configuration data to the
backend system there is a connection drop out the
client application simply tries to submit the data
again some time later; the user won’t mention this.
Limited resources of MT: MT have limited
energy supply. We don’t assume that there will be a
leap towards significant better batteries in the next
few years although we saw a considerable
improvement of available cpu-power and memory
for MT in the past. This implies we cannot do
extensive computations on MT (even if a powerful
CPU and big memory is available), because a CPU
under load consumes a lot of electricity. NS meet
this limitation: they don’t require extensive
computations on the MT since the actual logic of the
services is executed on the stationary servers of the
backend system.
Display quality of MT: MT have a small
display and thus can only display a limited amount
of information at one time, the resolution and colour
depth available are also limited.
Data input: MT don’t have a real keyboard or a
mouse, so it is cumbersome to enter data. NS meet
this limitation since after the initial configuration of
the service they do require a much data input. They
also make use of context information so the user has
to enter less data.
Short sessions: User sessions of mobile services
are usually short; typical i-Mode-sessions for
examples are shorter than two minutes, but there
may be 10-20 sessions per day and user (Zobel,
2001; pp. 109). When using a MT people don’t want
to browse for a long time (like they do when using a
personal computer) to find the information they
need, because the user interface of MT is limited and
users may be in a surrounding where they are
distracted; also the batteries wouldn’t stand longish
sessions. NS meet the postulation for short sessions:
the notifications are delivered as push messages (the
MT may play a ring tone to notice the user), so the
user has just to look at his MT and read the message.
The prevalent paradigm for mobile services
seems to be the delivery of www-like pull
documents in special markup languages (e.g.
cHTML, WML, XHTML), see for example the
services in the portals of the mobile network
operators. In contrast to NS the user experience of
such services is notable impaired by connection drop
outs and automatic updates of personal context
information are not possible; also pull-mode
delivery of information seems not to be adequate for
many mobile scenarios.
4 EXAMPLE SCENARIOS FOR
NOTIFICATION SERVICES
4.1 Classification of Examples
In this section we will give some examples for
mobile services from literature as well as from
NOTIFICATION SERVICES FOR MOBILE AND WIRELESS TERMINALS - A Class of Services Appropriate for
Mobile Scenarios
153
practice to demonstrate that despite their simplicity a
wide range of useful services for mobile scenarios
can be implemented as NS.
Since in most examples the current position of an
object is relevant we use a classification schema
similar to the one proposed by Turowski & Pousttchi
(2004, pp. 78) to classify the example services
(Figure 2). For this classification the “objects” —
the user/executer who calls the service and an
optional target object of the service — have to be
put in one of the following three classes with regard
to the relevance of their location:
The position of an object is relevant for the
service and dynamic and thus has to be
determined, e.g. the current position of the
user’s MT with an attached GPS-receiver.
The position of an object is relevant but
doesn’t change and thus can be looked up
in some kind of database, e.g. the position
of the nearest bus stop.
The position of an object is irrelevant for
the service or cannot be stated.
This schema results in 3 × 3 = 9 cases, the three
cases where the position of the invoker is “relevant
& dynamic” (G, H, I) are location based services.
For each example service we name the required
configuration data and the content of the
notification. All NS-examples offer a mobility-
specific value: the services provide time-critical
information or cover information-needs that
typically arise when the user is “on the move”.
4.2 Examples
Case A: irrelevant/dynamic
The user is interested in the position of the target
object, which might be a missing child or his car
respective a MT used by the child or installed in the
car. (Configuration: identifier of the target object;
Notification: position of current location of target
object.)
Case C: irrelevant/irrelevant
Neither the position of the invoker nor the target
object is relevant in this case. The notifications in
this case are triggered by time-critical events, e.g.
significant changes of stock quotes. We call this
class of services “alert services” (see Adya (2002)
for other examples of mobile alert services and their
popularity). (Configuration: identification code of
stock quote, threshold values; Notification: identifier
and current value of the stock-quote). Meanwhile
there are even Business Intelligence (BI) systems
that push notifications to MT if certain values (e.g.
Figure 2: Classification schema for examples.
Position of
service invoker
Position of
target object
irrelevant
irrelevant
relevant &
static
relevant &
static
relevant &
dynamic
relevant &
dynamic
(A) (B)
(G) (H) (I)
Example:
Track-your-
something
Example:
stock-quote-
alert
(C)
(D) (E) (F)
Example:
machine calls
nearest technican
Example:
Machine sends
status report to
control center
Example:
Friend finder
Example:
Virtual Memo
Example:
Weather alert
ICE-B 2006 - INTERNATIONAL CONFERENCE ON E-BUSINESS
154
available stock) are outside certain threshold values,
see MIK (2006) for example.
Another example is the notification of
performance after written exams at universities
(gov.mt (2006)): some students are very eager to
find out about their result as soon as possible, so
they would like to use a NS that sends their result
onto their MT (Configuration: the mapping of
surname to matriculation number is supposed to be
secret and thus can be used as authentication;
Notification: course identifier and result.)
The conventional form of authentication for
online banking is a password and a transaction
number (TAN) for each transaction. During a
phishing-attack a user enters these secrets into a web
site he wrongly believes to be the website of his
bank. To prevent this form of phishing a bank could
implement a two factor authentication (Wüest, 2005)
based on a mobile NS: after submission of the
transactions details (account number & bank code of
recipient, amount of money to be transferred) and
TAN on a non-mobile computer the web page shows
a challenge code. This challenge code has to be
entered on a MT (configuration) which then will
display the transaction details and a response code
(=notification). To actual execute the transaction the
response code has to be entered on the web page. A
phisher had to compromise both — the fixed
computer and the MT — to be successful which is
much harder.
The basic principle of m-ticketing is to use MT
for distribution and presentation of electronic tickets
(Hussin et al., 2005); a tickets is something that
certifies that the owner of the ticket has the right to
claim a certain service (using public transportation
vehicle or permission to entertainment events like
cinema, concert). Electronic tickets usually have
some kind of digital signature to hinder fraud (e.g.
SMS-message which states the date and destination
of a bus journey along with a certificate code). We
can model m-ticketing-systems as notification
system, if we consider the notification to contain the
ticket. The configuration is the booking of the ticket
(category of seat, number of zones in public
transport).
Case D: static/dynamic & Case F:
static/irrelevant
Since a NS is always invoked by the MT this case
implies that the MT has a fixed position, which is
only reasonable if it is embedded in a machine (e.g.
vending-machine). We do not consider this case here
although a machine calling the nearest service
technician (case D) or reporting its status to a control
center (case F) could be implemented as NS.
Case G: dynamic/dynamic
This service notifies a user, when another mobile
user of the service classified as “friend” is away less
than a certain defined distance, see the description of
“FriendZone” by Burak & Sharon (2004). (Noti-
fication: Name/nickname of the “friend” that is
within the defined distance; Configuration: identifier
for the group of friends and own nickname.) If
instead of a group identifier a profile (age, gender,
fields of interest) is used for the configuration of the
service we would obtain a “blind-date-finder”.
(Notification: “someone who matches your profile is
around”).
Other examples of NS for case G would be “Call
a taxi” or “call an ambulance/police car”, the target
object would be the nearest taxi or ambulance. If the
NS only forwards the request to a control center
where the choice which vehicle to send to the
location of the user is made manually we get case I.
(Configuration: type of vehicle requested; Noti-
fication: confirmation with optional estimated time
to wait.)
Case H: dynamic/static
To all positions in a given area (certain city or whole
country) the users of the service can assign virtual
memos with a message like “don’t visit the
restaurants at the corner of this street” (see also the
GeoNotes-system by Persson et al., 2002). Noti-
fications: If a user approaches a location with such a
virtual memo he gets a notification with the
message(s) of the virtual memo deposited by other
users. (Configuration: range, message to deposit at
current location, expiry date of message.)
Tourist guides are another example for NS in
case H (see also Sampat et al., 2005): the user
receives notifications with information concerning
the sights and places in his surrounding as he
wanders around in a district with places of interest.
The example of mobile advertising belongs also
to this case and was mentioned in section 2.1; the
target objects for this type of service are the shops of
the advertisers.
Munson & Gupta (2002) mention the idea of a
NS that notifies car drivers when they are
approaching a highway section with a construction
site.
NOTIFICATION SERVICES FOR MOBILE AND WIRELESS TERMINALS - A Class of Services Appropriate for
Mobile Scenarios
155
Case I: dynamic/irrelevant
There are NS which send alerts to people when a
thunderstorm or other menacing weather situation is
supposed to approach their current location, e.g. to
warn outdoor sportsmen (e.g. sailing, skiing). As
target object in this case we consider the “weather”;
since “weather” is a complex phenomenon, we
cannot assign a position to it. A location aware
weather alert service is provided by a German
insurer (VBK’s “Wind & Wetter”), see also
Fraunhofer (2006). (Notification: warning about
predicted change in the weather; Configuration:
events of interest, current location.)
5 SUMMARY AND FUTURE
WORK
We introduced notification services (NS) and argued
that this class of services is suitable for mobile
scenarios with regard to the technical restrictions
and the user experience. A lot of examples showed
that while simple NS cover a wide range of
reasonable usecases. Using public key cryptography
it is also possible to specify a simple protocol that
guarantees that the mobile network operator cannot
learn about the contents of the order and the actual
service provider cannot learn about the identity of
the user or send unsolicited messages.
The next step is the development of a software-
framework for NS; a framework in this sense
(Johnson & Foote, 1988) is a generic application for
a given class of applications (in our case: NS). Using
this framework a distinct NS could be implemented
as extension of the framework. In contrast to a
conventional software library a framework enforces
the reuse of the whole design (not just of parts of the
implementation, but also the architecture) and
handles the control flow, so the service specific parts
are called by the framework (“inversion of control”).
Altogether frameworks are supposed to promote a
quicker development of applications which are
simpler to maintain.
REFERENCES
Adya, A., Bahl, P. & Qiu, L., 2002. Characterizing Alert
and Browser Services for Mobile Clients. In
Proceedings of the USENIX Annual Technical
Conference.
Burak, A. & Sharon, T., 2004. Usage Patterns of
FriendZone — Mobile Location-Based Community
Services. In Proceedings of the 3
rd
International
Conference on Mobile and Ubiquitous Multimedia,
ACM.
Dey, A. K., 2001. Understanding and using Context.
Personal and Ubiquitous Computing Journal, Vol.
1(5), pp. 4-7.
Dubinko, M., 2003. XForms Essentials. O’Reilly, Upper
Saddle River, USA.
Fraunhofer, 2006. @ptus weather — Weather Information
on Demand. Brochure of Fraunhofer ISST, Berlin,
Germany.
Gov.met, 2006. Website of Government of Malta.
http://www.mobile.gov.mt/services.asp?mb:lang=en,
last accessed: 10.06.2006.
Hussin, W., Coulton, P. & Edwards, R., 2005. Mobile
Ticketing System Employing TrustZone Technology.
Proceedings of the International Conference on
Mobile Business (ICMB), Sydney, Australia, IEEE.
Johnson, R. & Foote, B., 1988. Designing Reusable
Classes. Journal of Object-Oriented Programming,
Vol. 1, pp. 23-35.
Kölmel, B. & Alexakis, S., 2002. Location Based
Advertising. In Proceedings of the 1st International
Conference on Mobile Business (ICMB), Athens,
Greece.
MIK, 2006. Information Any Time it’s Needed — Mobile
OLAP Reporting with MIK-BIS-Agent. Website of
MIK: http://www.mik.de (30 November 2005).
Munson, J. P. & Gupta, V. K., 2002. Location-Based
Notification as General-Purpose Service. In
Proceedings of the 2
nd
International Workshop on
Mobile Commerce, ACM, pp. 40-44.
Persson, P., Espinoza, F., Fagerberg, P., Sandin, A. &
Cöster, R., 2002. GeoNotes: A Location-based
Information System for Public Spaces. Designing
Information Spaces: The Social Navigation Approach,
Spring, pp. 151-173.
Satyanarayanan, M., 1996. Fundamental Challenges in
Mobile Computing. In Proceedings of the Symposium
on the Principles of Distributed Computing,
Philadelphia, Pennsylvania, USA, ACM.
Sampat, M., Kumar, A., Prakash, A. & McCrickard, D. S.,
2005. Increasing Understanding of a New
Environment using Location-Based Notification
Systems. In Proceedings of the 11
th
International
Conference on Human-Computer Interaction, Las
Vegas, NV.
Turowski, K. & Pousttchi, K., 2004. Mobile Commerce (in
German). Springer, Berlin et al.
Wüest, C., 2005. Phishing in the Middle of the Stream —
Today’s Threats to Online Banking. Proceedings of
the 8
th
Association of Anti-Virus Asia Researchers
Conference (AVAR), Tianjin, China.
Zobel, J., 2001. Mobile Business und M-Commerce (in
German), Hanser Publishing, Munich, Germany.
ICE-B 2006 - INTERNATIONAL CONFERENCE ON E-BUSINESS
156
