A Comparison of Document Clustering Algorithms

Yong Wang

and Julia Hodges

Department of Computer Science & Engineering, Mississippi State University

Box 9637, Mississippi State, MS 39762

Abstract. Document clustering is a widely u

sed strategy for information

retrieval and text data mining. This paper describes the preliminary work for

ongoing research of document clustering problems. A prototype of a document

clustering system has been implemented and some basic aspects of document

clustering problems have been studied. Our experimental results demonstrate

that the average-link inter-cluster distance measure and TFIDF weighting

function are good methods for the document clustering problem. Other

investigators have indicated that the bisecting K-means method is the preferred

method for document clustering. However, in our research we have found that,

whereas the bisecting K-means method has advantages when working with

large datasets, a traditional hierarchical clustering algorithm still achieves the

best performance for small datasets.

1 Introduction

Data clustering partitions a set of unlabeled objects into disjoint/joint groups of

clusters. In a good cluster, all the objects within a cluster are very similar while the

objects in other clusters are very different. When the data processed is a set of

documents, it is called document clustering. Document clustering is very important

and useful in the information retrieval area. It can be applied to facilitate the

retrieving the useful documents for the user. Generally, the feedback of an

information retrieval system is a ranked list ordered by their estimated relevance to

the query. When the volume of an information database is small and the query

formulated by the user is well defined, this ranked list approach is efficient. But for a

tremendous information source, such as the World Wide Web, and poor query

conditions (just one or two key words), it is difficult for the retrieval system to

identify the interesting items for the user. Applying documenting clustering to the

retrieved documents could make it easier for the users to browse their results and

locate what they want quickly. A successful example of this application is VIVISIMO

(http://vivisimo.com/), which is a Web search engine that organizes search results

with document clustering. Another application of document clustering is the

automated or semi-automated creation of document taxonomies. A good taxonomy

for Web documents is Yahoo.

This paper describes our preliminary work for research of document clustering

oblems. A prototype of a document clustering system has been implemented and

some basic aspects of document clustering problem have been studied. In section 2,

some document clustering algorithms are introduced. Section 3 presents our

Wang Y. and Hodges J. (2005).

A Comparison of Document Clustering Algorithms.

In Proceedings of the 5th International Workshop on Pattern Recognition in Information Systems, pages 186-191

DOI: 10.5220/0002557501860191

 SciTePress

experimental results and analysis for different cluster distance measures, different

weighting functions, and different clustering algorithms. Section 4 lists our final

conclusions.

2 Documents Clustering Algorithms

Hierarchical clustering generates a hierarchical tree of clusters. Hierarchical methods

can be further classified into agglomerative methods (HAC) and divisive methods.

Partitioning clustering methods allocate data into a fixed number of non-empty

clusters. All the clusters are in the same level. The most well-known partitioning

methods following this principle are the K-means method and its variants. The

buckshot method is a combination of the K-means method and HAC method. HAC

method is used to select the seeds and then the K-means method is applied. The

buckshot method is successfully used in a well-known document clustering system,

the Scatter/Gather (SG) system [2]. The K-means method can also be used to generate

hierarchical clusters. Steinbach, Karypis, and Kumar proposed bisecting K-means

algorithm to generate hierarchical clusters by applying the basic K-means method

recursively [7].

Besides these basic clustering algorithms, some particular algorithms for document

clustering were proposed. Zamir has described the use of a suffix tree for document

clustering [8]. Beil, Ester, and Xu proposed two clustering methods, FTC (Frequent

Term-based Clustering) and HFTC (Hierarchical Frequent Term-based Clustering),

based on frequent term sets [1]. Fung proposed another hierarchical document

clustering method based on the frequent term set, HIFC (Frequent Itemset-based

Hierarchical Clustering), to improve the HFTC method [3].

3 Experiments

3.1 Experimental Data and Evaluation Method

We collected 10,000 abstracts from journals belonging to ten different areas. For each

area, 1000 abstracts were collected. Table 1 lists the areas and the names of the

journals. This full data set was divided evenly into 5 subsets. Each subset contains

200 abstracts from each category and they are named as FDS 1 - 5. Another mini data

set is selected from the full dataset. There are 1000 abstracts from 10 categories in

this mini dataset. This mini dataset is partition into 5 groups evenly too. They are

named as MDS 1 - 5.

All these abstracts were cut into the sentences with MXTERMINATOR [6]. Then

the tokens were identified from each sentence with the Penn Treebank tokenizer. The

lemmatizer in WordNet was used to convert each token into lemma [4]. All the stop

words are filtered. Finally, a document is converted into a list of lemmas. These

lemmas will be used to construct the feature vector for each document.

The evaluation methods F-measure and entropy, which have been used by a

number of researchers, including Steinbach, Karypis, and Kumar [7], will be used in

187

our experiments. Both entropy and F-measure are external quality measures. F-

measure is a combination of precision and recall which come from information

retrieval area. A higher F-measure indicates a better performance. The entropy for

each cluster reflects the homogeneity of each cluster. A smaller value indicates a

higher homogeneity. The detailed formula of F-measure and entropy is provided in

[7].

Table 1. Journal Abstracts Data Set

Area Journal Name Area Journal Name

Artificial

Intelligence

Artificial Intelligence Material Journal of Electronic Materials

Ecology Journal of Ecology Nuclear IEEE Transactions on Nuclear Science

Economy Economic Journal Proteomics PubMed

History Historical Abstracts Sociology Journal of Sociology

Linguistics Journal of Linguistics Statistics Journal of Applied Statistics

Regression Analysis

Table 2. Comparison of Inter-Cluster Distance Measures

FDS 1 FDS 2 FDS 3 FDS 4 FDS 5 MDS 1 MDS 2 MDS 3 MDS 4 MDS 5

F-measure

S-link 0.19 0.23 0.25 0.19 0.19 0.52 0.35 0.40 0.37 0.50

C-link 0.18 0.18 0.18 0.18 0.18 0.18 0.18 0.18 0.18 0.19

A-link

0.74 0.55 0.60 0.59 0.66 0.77 0.77 0.78 0.63 0.77

Entropy

S-link 2.17 2.08 2.04 2.19 2.17 1.29 1.70 1.60 1.62 1.33

C-link 2.29 2.29 2.29 2.29 2.29 2.20 2.20 2.20 2.20 2.17

A-link

0.73 1.19 0.98 1.09 0.91 0.58 0.51 0.52 0.84 0.64

3.2 Experimental Results and Analysis

Comparison of Different Cluster Distance Measures in HAC Method

There are three generally used distance measures between clusters, single link

(minimum distance), complete link (maximum distance), and average link (average

distance). The comparison results of these three method are listed in table 2. In both

F-measure and entropy, the average-link method achieved the best performance for all

full data sets and mini data sets. This result is consistent with Steinbach, Karypis, and

Kumar [7]. Different from the single-link and complete-link, the average-link

measure considers every pairwise distance between two elements in two clusters and

averages them. This measure reflects a global relatedness between two clusters.

Comparison of Term Weighting Methods

Different term weighting methods may be used in the vector space model. The

simplest method is a binary weighting function in which a value of 1 indicates the

occurrence of that term and a value of 0 indicates the absence. Another term

weighting method for w

is term frequency (tf). In this method, each feature vector is

represented by a list of occurrence frequencies of all terms. In order to avoid the

effect of the varying lengths of the documents, all the occurrence frequencies should

be normalized before being used. Inverse document frequency (idf) is a method that

188

tries to filter those terms that occur too frequently. The most widely used term

weighting method in the vector space model is tf-idf which is a combination of tf and

idf.

Binary(Bi), Term Frequency (Tf), and Term Frequency Inverse Document

Frequency (Tf-Idf) were tested in this experiment. The HAC clustering method using

average-link cluster distance measure was used as the clustering method. Results of

this experiment are listed in table 3. Notice that TFIDF had the best results for all data

sets in both F-measure and entropy. From the introduction of these three methods

given in section 3, we know that both the binary method and TF method try to weight

a feature based just on the individual document. They assume that a feature with a

high frequency in a document may be a key word for this document and should be

useful to distinguish this document from others. This assumption is untenable when

this feature occurs in most or all documents in the whole collection. The IDF measure

helps to evaluate the importance of a word to the whole collection. As a combination

of the TF and IDF methods, the TFIDF weighting function tries to select the features

which are important for both the individual document and the whole collection.

Table 3. Comparison of Term Weighting Methods

FDS 1 FDS 2 FDS 3 FDS 4 FDS 5 MDS 1 MDS 2 MDS 3 MDS 4 MDS 5

F-measure

Bi 0.27 0.23 0.30 0.36 0.19 0.51 0.65 0.44 0.43 0.31

Tf 0.27 0.23 0.31 0.44 0.18 0.73 0.64 0.53 0.55 0.55

Tf-

Idf

0.74 0.55 0.60 0.59 0.66 0.77 0.78 0.78 0.63 0.77

Entropy

Bi 2.00 2.16 1.96 1.75 2.24 1.12 0.81 1.40 1.39 1.79

Tf 2.03 2.15 1.81 1.52 2.28 0.59 0.78 1.04 1.03 1.04

Tf-

Idf

0.73 1.19 0.98 1.09 0.91 0.58 0.51 0.52 0.84 0.64

Comparison of Clustering Algorithms

Four basic clustering algorithms, K-means, buckshot, HAC, and bisecting K-means,

were selected for comparison. In this experiment, K-means method, buckshot method,

and bisecting K-means method are executed 20 times to alleviate the effect of a

random factor. The F-measure and entropy listed here are the average values of 20

different results. In five full data sets, we found that the bisecting method outperforms

all the other methods. The K-Means method and buckshot method achieve similar

results. The HAC method, only in the first dataset, gets a similar result to K-means

and buckshot method. But for the other four datasets, the results of the HAC method

are less than that of the K-means method and buckshot method by about 10-15

percentage points. In the five mini data sets, HAC achieves the best performance. The

results of K-means, buckshot, and the bisecting K-means method are similar and low.

Our results for the full data set are consistent with the results of Steinbach, Karypis,

and Kumar [7]. A comprehensive analysis provided by Steinbach et al. explained that

the nature of the document clustering problem is the reason for the worse performance

of hierarchical approaches and the good performance of the bisecting K-means

method. In all these clustering algorithms, two documents that share more common

words will be considered as more similar to each other. The problem is that two

189

documents consisting of the same set of words may be about two totally different

topics. It is very possible that the nearest neighbors of a document may belong to

different categories. In the HAC method, if two documents were assigned into the

same group, they will always be in the same group. This assignment may be optimal

in that step, but from the view of the whole partition, it may not be optimal. The HAC

method just tries to get local optimality in each step with no attempt for global

optimality. The advantage of the K-means method, buckshot method and bisecting K-

means method is their adjusting of each cluster after each iteration. This reassignment

is helpful for a global optimality. Compared with the K-means method and buckshot

method, bisecting K-means can generate more evenly partitioned clusters. A balanced

performance for each cluster is helpful for a higher global result.

Table 4. Comparison of Clustering Algorithms

FDS 1 FDS 2 FDS 3 FDS 4 FDS 5 MDS 1 MDS 2 MDS 3 MDS 4 MDS 5

F-measure

KM 0.77 0.72 0.79 0.72 0.74 0.41 0.48 0.42 0.39 0.42

BS 0.73 0.73 0.75 0.74 0.72 0.51 0.51 0.47 0.48 0.48

HAC 0.74 0.55 0.60 0.59 0.66

0.77 0.77 0.78 0.63 0.77

BiKM

0.90 0.85 0.87 0.86 0.88

0.38 0.40 0.34 0.36 0.37

Entropy

KM 0.60 0.73 0.60 0.74 0.67 1.50 1.35 1.50 1.61 1.50

BS 0.67 0.70 0.65 0.72 0.71 1.28 1.24 1.38 1.37 1.34

HAC 0.73 1.19 0.98 1.09 0.91

0.58 0.51 0.52 0.84 0.64

BiKM

0.40 0.50 0.46 0.51 0.45

1.60 1.55 1.71 1.63 1.63

Then why is the HAC clustering method the best one for the mini datasets? We

think the major reason is the size of the data set. There are 2000 abstracts in each full

data set and they are considered as 2000 clusters in the initial step of the HAC method.

We know in each iteration of the HAC method, two nearest clusters are merged

together to get local optimality. This optimality may be not helpful, and may even be

harmful, for the next iteration. This loop will be repeated 1990 times to get the final

10 clusters; the advantages of each step will have counteracted with each other. Since

there is no global reassignment procedure in the HAC method, the final partitions

cannot be improved at any steps. In our mini data set, there are only 200 abstracts in

each set. The iteration was repeated only 190 times. The advantage of the optimality

in each step is still higher than that of the reassignment functions in the K-means,

buckshot, and bisecting methods. When we checked the detailed debugging

information for the K-means, buckshot, and bisecting methods, we found that for the

mini data sets, K-means, buckshot, and the bisecting method had only 1 or 2 iterations.

This means that, for those small datasets, the results of K-means, buckshot, and

bisecting method are similar to that of a randomly partitioning. Notice that in the full

data set, the performance of the buckshot method is similar to that of the K-means

method. But in the mini data set, the performance of the buckshot method is always

higher than that of K-means for all five mini datasets. This demonstrates that the use

of HAC for seed selection is helpful for small data sets but not for the large data sets.

There are eight data sets were used for evaluation in Steinbach, Karypis, and

Kumar’s experiments [7]. The largest data set contains about 3000 documents and

smallest one contains about 1000 documents. This size is similar to the size of our full

190

data set. This also demonstrates that the good performance of bisecting K-means

method achieved by in Steinbach, Karypis, and Kumar’s experiments is also based on

large data set.

4 Conclusions

In this paper, we described a general document clustering system prototype and

discussed three ways to achieve better performance. A brief overview about different

document clustering algorithms, vector weighting functions, and distance measures

was provided. From our experimental results, we can below conclusions.

For the HAC clustering method, the average-link inter-clustering distance measure

is better than the single-link method and complete-link method. For weighting

functions in the vector space model, the TFIDF method is better than the binary

method and TF method. The TFIDF method assigns a weight to a feature by

combining its importance in a document and its distinguishability for whole document

set. An important term may be a medium frequency word instead of a high frequency

word (too common) or a low frequency word (too particular). For large data sets, the

bisecting algorithm outperforms all the other methods. But for small data sets, the

HAC method gets the best performance. The K-means method has a performance that

is similar to that of the buckshot method for large data sets. But for small data sets,

the buckshot method is better than the K-means method. The advantage of the HAC

method on small data sets improves the performance of the buckshot method.

References

1. F. Beil, M. Ester, and X. Xu, “Frequent Term-Based Text Clustering,” Proc. of the 8th

International Conference on Knowledge Discovery and Data Mining, 2002.

2. D. Cutting, D. Karger, J. Pedersen, and J. Tukey, “Scatter/Gather: a Clusterbased Approach

to Browsing Large Document Collection,” Proc. of the 15th ACM SIGIR Conference,

Copenhagen, Denmark, 1992, pp. 318-329.

3. B. C. M. Fung, Hierarchical Document Clustering Using Frequent Itemsets, Master Thesis,

Dept. Computer Science, Simon Fraser University, Canada, 2002.

4. G. A. Miller, R. Beckwith, C. Fellbaum, D. Gross, and K. J. Miller, “Introduction to

WordNet: An On-Line Lexical Database,” International Journal of Lexicography, vol. 3, no.

4, 1990, pp. 235-312.

5. A. Ratnaparkhi, “A Maximum Entropy Part-Of-Speech Tagger,” Proc. of the Empirical

Methods in Natural Language Processing Conference, University of Pennsylvania, May

1996, pp. 17-18.

6. J. C. Reynar and A. Ratnaparkhi, “A Maximum Entropy Approach to Identifying Sentence

Boundaries,” Proc. of the Fifth Conference on Applied Natural Language Processing,

Washington, D.C., March 31-April 3, 1997.

7. M. Steinbach, G. Karypis, and V. Kumar, “A Comparison of Document Clustering

Techniques,” KDD Workshop on Text Mining, 2000.

8. O. Zamir, Clustering Web Documents: A Phrase-Based Method for Group Search Engine

Results, Ph.D. dissertation, Dept. Computer Science & Engineering, Univ. of Washington,

1999.

191
