USING ENSEMBLE AND LEARNING TECHNIQUES TOWARDS
EXTENDING THE KNOWLEDGE DISCOVERY PIPELINE
Yu-N Cheah, Sakthiaseelan Karthigasoo, Selvakumar Manickam
School of Computer Sciences, Universiti Sains Malaysia, 11800 USM Penang, Penang, Malaysia
Keywords: Knowledge discovery, Clustering ensemble, Neural network ensemble, Discr
etization, Rough set analysis
Abstract: Knowledge discovery presents itself as a very useful technique to transform enterprise data into actionable
knowledge. However, their effectiveness is limited in view that it is difficult to develop a knowledge
discovery pipeline that is suited for all types of datasets. Moreover, it is difficult to select the best possible
algorithm for each stage of the pipeline. In this paper, we define (a) a novel clustering ensemble algorithm
based on self-organizing maps to automate the annotation of un-annotated medical datasets; (b) a data
discretization algorithm based on Boolean Reasoning to discretize continuous data values; (c) a rule filtering
mechanism; and (d) to extend the regular knowledge discovery process by including a learning mechanism
based on neural network ensembles to produce a neural knowledge base for decision support. We believe
that this would result in a decision support system that is tolerant towards ambiguous queries, e.g. with
incomplete inputs. We also believe that the boosting and aggregating features of ensemble techniques would
help to compensate for any shortcomings in some stages of the pipeline. Ultimately, we combine these
efforts to produce an extended knowledge discovery pipeline.
1 INTRODUCTION
The generation of a huge amount of data by an
enterprise is of great concern to decision makers.
This problem is compounded by the many
environmental challenges that an enterprise faces in
the effort to produce better products and services. It
is highly crucial to know what goes on in its
business transactions both internally and externally
and to examine the heart of an enterprise’s
transactions, that is its data, and to transform it into
actionable knowledge through the process of
knowledge discovery.
Knowledge discovery is a series of processes,
whi
ch can be likened to a pipeline to find hidden but
potentially useful information and patterns in data
(Fayyad et al., 1996). This series of processes
involves preparation on the data, the application of
data mining algorithms on the data and finally the
interpretation and/or visualization of the data mining
results. The number of ways that a pipeline can be
developed is perhaps limitless in view that there are
many ways in which data preparation, data mining
and interpretation or visualization can be achieved.
Current knowledge discovery pipelines have
been
proven effective to a certain extent in
discovering hidden knowledge from various
datasets. However, their effectiveness is limited as it
is difficult to develop a pipeline that is suited for all
types of datasets. Moreover, it is difficult to select
the best possible algorithm for each stage of the
pipeline. It is challenging to develop an approach
that would minimize the impact of a sub-optimal
choice of algorithm at each stage of the pipeline.
Therefore, in this paper, we aim to define (a) a
no
vel clustering ensemble algorithm based on self-
organizing maps (SOM) to automate the annotation
of un-annotated medical datasets; (b) a data
discretization algorithm based on Boolean
Reasoning to discretize continuous data values; (c) a
rule filtering mechanism employing a Rule Quality
Function; and (d) to extend the regular knowledge
discovery process by including a learning
mechanism based on neural network ensembles
(NNE) to produce a neural knowledge base for
decision support. We believe it is advantageous to
produce a knowledge base that is trained from
decision rules to develop a decision support system
that is tolerant towards ambiguous queries, e.g. with
incomplete inputs. We also believe that the boosting
and aggregating features of ensemble techniques
would help to compensate for any shortcomings in
some stages of the pipeline. Ultimately, we combine
408
Cheah Y., Karthigasoo S. and Manickam S. (2005).
USING ENSEMBLE AND LEARNING TECHNIQUES TOWARDS EXTENDING THE KNOWLEDGE DISCOVERY PIPELINE.
In Proceedings of the Seventh International Conference on Enterprise Information Systems , pages 408-411
DOI: 10.5220/0002538104080411
Copyright
c
SciTePress
these efforts to produce an extended knowledge
discovery pipeline.
1.1 Ensembling Techniques
Ensembling is a technique that harnesses the
capabilities of a predetermined number of
algorithms or processes that perform the same task
to obtain an improved result.
Ensembling involves two main steps. The first is
the execution of the individual algorithm. Two
popular approaches for this are boosting (Freund and
Schapire, 1995) and bagging (bootstrap aggregation)
(Breiman, 1996). In boosting, the output of a
particular individual algorithm becomes the input for
another algorithm. The outputs are boosted through
re-sampling or re-weighting until all the algorithms
have had a hand in processing the input. In bagging,
several subsets are derived from the original input
and each one is fed to a different algorithm to be
processed separately. The second step involves the
combination of the outputs to produce a single
consolidated output, i.e. as if only a single instance
of the algorithm was used. Techniques such as
voting and averaging are popularly used for this
purpose.
An example of an ensembling technique is the
NNE (Hansen and Salamon, 1990) where the
learning capabilities of a predetermined number of
neural networks is utilized to obtain improved
generalizations or predictions (Zhou, et al., 2003).
Another example of the ensembling technique is in
the area of clustering (Yang and Kamel, 2003).
1.2 Knowledge Discovery Pipelines
An example in developing a knowledge discovery
pipeline for symbolic rules extraction from un-
annotated datasets is by Abidi and Hoe (2002) which
applies rough set analysis. This pipeline, or
workbench as they have called it, includes steps to
pre-process and cluster un-annotated datasets
resulting in annotated versions of the original
datasets. The workbench then proceeds to discretize
the data and generate rules. These rules are finally
filtered.
For clustering, the workbench employs the K-
Means algorithm while the Chi Squared and
Entropy-MDL algorithms were used to discretize the
annotated version of the data. Rough set analysis
was then used to compute the reducts and generate
symbolic rules. Here, the reducts were derived using
genetic algorithm. The rules were then filtered using
a rule quality index computation.
Another work on a knowledge discovery pipeline
involves the discretization of numerical attributes for
machine learning (Risvik, 1997). This pipeline
includes steps to pre-process and then discretize
annotated datasets using discretization algorithms
such as Chi Squared, Entropy, Naïve and Orthogonal
Hyperlanes. Rough set analysis was used to generate
rules from the discretized data. Reducts is generated
using Johnson’s Algorithm (1974) and followed by a
rule generation process.
From our observation, the stages involved in
knowledge discovery are more or less standardised
and normally ends with a filtering stage. It appears
that much of the research in knowledge discovery
pipelines involves the exploration of various
algorithms that can be applied at each stage of the
pipeline. We believe that existing pipeline
construction can be extended further by including a
learning stage and that the algorithms can be made
more effective by employing ensemble techniques,
i.e. by being made to ‘work harder’ to compensate
for any shortcomings as mentioned earlier.
2 THE EXTENDED KNOWLEDGE
DISCOVERY PIPELINE
Our extended knowledge discovery pipeline consists
of six stages (see Figure 1): data preparation,
clustering, discretising, rough set analysis, rule
filtering and learning.
2.1 Stage I: Data Preparation
Data preparation ensures the cleanliness or
completeness of the dataset. Various strategies are
currently employed to remove redundant data,
missing values and other errors. For our purposes,
we use the mean/mode fill technique to address the
issues of missing values. We observed that
mean/mode fill produces better results when
compared to other data cleansing techniques such as
combinational completion in terms of accuracy in
Data
Repository
Knowledge
Base
EXTENDED KNOWLEDGE DISCOVERY PIPELINE
Data
Clustering
Data
Clustering
Data
Discretisation
Data
Discretisation
Rule
Generation
Rule
Generation
Learning
Learning
Rule Filtering
Rule Filtering
Data
Preparation
Data
Preparation
Data
Repository
Knowledge
Base
EXTENDED KNOWLEDGE DISCOVERY PIPELINE
Data
Clustering
Data
Clustering
Data
Discretisation
Data
Discretisation
Rule
Generation
Rule
Generation
Learning
Learning
Rule Filtering
Rule Filtering
Data
Preparation
Data
Preparation
Data
Repository
Knowledge
Base
EXTENDED KNOWLEDGE DISCOVERY PIPELINE
Data
Clustering
Data
Clustering
Data
Discretisation
Data
Discretisation
Rule
Generation
Rule
Generation
Learning
Learning
Rule Filtering
Rule Filtering
Data
Preparation
Data
Preparation
Fi
g
ure 1: The extended knowled
g
e discover
y
p
i
p
eline
USING ENSEMBLE AND LEARNING TECHNIQUES TOWARDS EXTENDING THE KNOWLEDGE DISCOVERY
PIPELINE
409
view that the mean/mode fill substitutes missing
values with the mean value for numerical attributes
of all observed entries for that attribute. For string
attributes, missing values are substituted by the
mode value, i.e. the most frequently occurring value
among the observed entries for that attribute. In
contrast, combinational completion is perceived to
be more complex in view that it expands each
missing value for each object into the set of possible
values. That is, an object is expanded into several
objects covering all possible combinations of the
object’s missing values. This could lead to the
number of possible combination for objects with
multiple missing values to grow very rapidly.
2.2 Stage II: Data Clustering
With un-annotated datasets in mind, this next phase
involves the utilization of a novel clustering
ensemble algorithm to annotate the previously un-
annotated dataset. This step involves the application
of Kohonen’s SOM as the basic technique for
clustering the un-annotated dataset. It is not our aim
to explore in detail any enhancements to SOMs.
However, here, we aim to boost the results of the
SOM clustering through re-sampling. Training
instances that were wrongly predicted in the kth
classifier will play a more important role in the
k+1th classifier to produce optimum clustering
results, i.e. the best possible annotation of the
previously un-annotated dataset. We argue that the
application of boosting and SOM techniques in a
clustering mechanism is novel in view that it is more
commonly applied within the context of other neural
networks applications. Moreover, previous work on
clustering ensembles focused more on using
aggregation (Dimitriadou et al., 2003) and
hypergraph partitioning (Strehl and Ghosh, 2002)
strategies.
2.3 Stage III: Data Discretization
Following the clustering stage, we then discretize
the annotated results. The objective of discretization
is basically to clearly differentiate between
continuous values that are likely to be present in the
dataset. Continuous values that lie within each
interval are then mapped to the same discrete value.
This process would result in better rule generation.
Here, we use Boolean Reasoning and we have
observed that it best suits our purpose over other
techniques that we have explored such as the
Entropy/Minimum Description Length (MDL)
technique. This is because Boolean Reasoning
computes a larger interval range compared to
Entropy/MDL. The interval range computed by
Entropy/MDL is 0.1, e.g. 1.15-1.25. We believe that
small interval range will not be sufficiently succinct
and practical to discretize data as there will be very
few datasets that are categorised in that interval. In
this sense, Boolean Reasoning computes larger
interval cuts which lead to a lower number of
categories being computed and, hence, allow clearer
rules to be generated in the next stage.
2.4 Stage IV: Rule Generation
For the data mining proper, we choose to carry out
rule generation as the product of the pipeline based
on rough set analysis. We compute reducts using
genetic algorithm, a technique that is widely used for
this purpose in rough set analysis. We then look into
a number of sub-tables which will be randomly
sampled from the datasets. Proper reducts are
computed from each of these samples. The reducts
that occur the most often across these sub-tables are
in some sense the most stable and can be categorised
as dynamic reducts. Based on the computation of the
reducts, rules will be generated. This would
constitute knowledge as it is potentially capable of
capturing complex relationship between attributes
and decision values of the dataset.
2.5 Stage V: Rule Filtering
This rule filtering phase follows the induction of
rules. This stage basically cleanses the output of the
rule generation stage to ensure that weak rules are
removed. For this purpose, we define a quantitative
rule evaluation technique leading towards the
definition of what we call a Rule Quality Function
which would indicate the quality of an induced rule.
Here, the Rule Quality Function is based on the
support, consistency and coverage measurements
used by Michalski (1983). After determining the
quality of the rules, the actual filtering process can
then be carried out. We observed that statistical
methods like the mean and Receiver Operating
Characteristic curve (ROC) serves as a good
indicator in the rule filtering. This can be viewed as
an initial step towards ensuring that the rule base
generated by the rule induction process using the
rough set theory is of good quality.
2.6 Stage 6: Learning
The link between this learning phase and the rule
filtering phase is novel where the filtered rules will
be trained. We argue that the inclusion of this
learning stage to the overall knowledge discovery
pipeline is novel in view that most pipelines would
ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS
410
stop after rule filtering. Here, we employ NNE
techniques to effectively learn the filtered rules. This
is done by using different neural network
algorithms, i.e. Multilayer Perceptron, Generalized
Feedforward Network, Modular Neural Network and
Radial Basis Function Networks. For this NNE, the
bagging technique would be employed and this
involves re-sampling or re-weighting the training
instances where all the results of each neural
network are aggregated to produce better
predictions. Here, we have done the aggregation via
averaging. This will produce a neural knowledge
base (weights) that would be considered the best
abstraction of the knowledge from the rules and
would serve as a robust repository for decision
support even in the event that users do not provide
sufficient input.
3 CONCLUSION
We would like to highlight that the knowledge
discovery pipeline leaves much to be explored in
terms of the algorithms and techniques that can be
applied at each stage of the pipeline. For our
extended pipeline, we have proposed mean/mode fill
for data preparation, clustering ensemble with SOM
for clustering or data annotation, Boolean Reasoning
for discretization, rough set analysis for rule
extraction, Rule Quality Function (based on support,
consistency and coverage) for rule filtering and
finally, a NNE for rule learning. In addition to
contributing towards an extended knowledge
discovery pipeline, we believe that this featured
work will provide an alternative inductive approach
to support diagnosis and decision support especially
in the medical domain.
With the incorporation of ensembling techniques
for clustering and learning, we hope to minimize the
need, or to reduce the temptation, to switch to other
algorithms by making the most out to the selected
algorithm, i.e. SOM and our ‘cocktail’ of neural
network algorithms. We are currently evaluating
each stage of our extended knowledge discovery
pipeline using continuous, discrete and also possibly
mixed (continuous and discrete) medical datasets
such as those on breast cancer and thyroid disease.
We will also be exploring other methods of
clustering ensembles in the second stage to be
integrated into our extended pipeline in future. We
believe this extended pipeline would result in more
accurate knowledge-based predictions in our effort
to make medical diagnosis and decision support
more reliable and trustworthy.
REFERENCES
Abidi, S.S.R. and Hoe, K.M., 2002. Symbolic Exposition
of Medical Data-Sets: A Data Mining Workbench to
Inductively Derive Data-Defining Symbolic Rules. In
Proceedings of the 15th IEEE Symposium on
Computer Based Medical Systems (CBMS 2002).
Maribor, Slovenia.
Breiman, L., 1996. Bagging Predictors. Machine
Learning. Vol. 24, pp. 123-140.
Dimitriadou, E., Weingessel, A., and Hornik, K., 2003. A
cluster ensembles framework. In Abraham, A.,
Köppen, M., and Franke, K. (eds.), Design and
Application of Hybrid Intelligent Systems. Frontiers in
Artificial Intelligence and Applications. Vol. 104, pp.
528-534. IOS Press.
Fayyad, U., Piatetsky-Shapiro, G. and Smyth, P., 1996.
From Data Mining to Knowledge Discovery in
Databases. AI Magazine. Vol. 17, No. 3, pp. 37-54.
Freund, Y. and Schapire, R.E., 1995. A Decision-
Theoretic Generalization of On-line Learning and an
Application to Boosting. In Proceedings of the Second
European Conference on Computational Learning
Theory. Barcelona, Spain, pp. 23-37.
Hansen, L.K. and Salamon, P., 1990. Neural Network
Ensembles. IEEE Transactions on Pattern Analysis
and Machine Intelligence. Vol. 12, pp. 993-1001.
Johnson, D.S., 1974. Approximation Algorithms for
Combinational Problems. Journal of Computer and
System Sciences, Vol. 9, pp. 256-278.
Michalski, R.S., 1983. A Theory and Methodology of
Inductive Learning. In Michalski, R., Carbonell, J. and
Mitchell, T. (eds.), Machine Learning. An
Artificial Intelligence Approach, pp. 83-134. Springer-
Verlag.
Risvik, K.M., 1997. Discretization of Numerical
Attributes - Preprocessing for Machine Learning.
Project Report. Knowledge Systems Group,
Department of Computer Systems and Telematics,
Norwegian Institute of Technology, University of
Trondheim, Norway.
Strehl, A., and Ghosh, J., 2002. Cluster ensembles - a
knowledge reuse framework for combining multiple
partitions. Journal on Machine Learning Research.
Vol. 3, pp. 583-617.
Yang, Y and Kamel, M., 2003. Clustering Ensemble
Using Swarm Intelligence. In IEEE Swarm
Intelligence Symposium. Indianapolis, Indiana, USA.
Zhou, Z.H., Jiang, Y. and Chen, S.-F., 2003. Extracting
Symbolic Rules from Trained Neural Network
Ensembles. AI Communications. Vol. 16, No. 1, pp. 3-
15.
USING ENSEMBLE AND LEARNING TECHNIQUES TOWARDS EXTENDING THE KNOWLEDGE DISCOVERY
PIPELINE
411
