STRATEGIES FOR SERVICE COMPOSITION IN P2P NETWORKS
Jan Gerke
Swiss Federal Institute of Technology ETH Zurich, Computer Engineering and Networks Lab TIK
Gloriastrasse 35, CH-8092 Zurich, Switzerland
Peter Reichl
Telecommunications Research Center FTW Vienna
Donau City Strasse 1, A-1220 Vienna, Austria
Burkhard Stiller
University of Zurich, Department of Informatics IFI and ETH Zrich, TIK
Winterthurerstrasse 190, CH-8057 Zurich, Switzerland
Keywords:
Service Composition, Peer-to-Peer Network, Service-oriented Architecture.
Abstract:
Recently, the advance of service-oriented architectures and peer-to-peer networks has lead to the creation of
service-oriented peer-to-peer networks, which enable a distributed and decentralized services market. Apart
from the usage of single services, this market supports the merging of services into new services, a process
called service composition. However, it is argued that for the time being this process can only be carried out
by specialized peers, called service composers. This paper describes the new market created by these service
composers, and models mathematically building blocks required for such a service composition. A general
algorithm for service composition developed can be used independently of solutions for semantic difficulties
and interface adaption problems of service composition. In a scenario for buying a distributed computing
service, simulated strategies are evaluated according to their scalability and the market welfare they create.
1 INTRODUCTION
In recent years the development of distributed systems
especially the Internet has been influenced heavily
by two paradigms: Service-orientation and peer-to-
peer (P2P) (A. Oram (Editor), 2001). The benefit
of service-oriented architectures (SOA) is their sup-
port of loose coupling of software components, i.e.,
providing a high degree of interoperability and reuse
(He, 2003) by standardizing a small set of ubiquitous
and self-descriptive interfaces, e.g., the standardiza-
tion of web services (World Wide Web Consortium,
2004) by the world wide web consortium, and its im-
plementations like .NET (Microsoft Developer Net-
work, 2004). Additionally, P2P file sharing systems
like BitTorrent have proven to be scalable content
distribution networks (Izal et al., 2004). This scal-
ability is achieved by the distributed nature of P2P
networks. Rather than using centralized server in-
frastructure, they rely on distributed hosts, the peers,
and their self-organization abilities. Lately, P2P net-
works have also been put to commercial use. For
instance, Blizzard uses the BitTorrent technology to
distribute program updates to their customer base of
several hundred thousands, thus reducing the need for
a centralized server infrastructure (Blizzard Corpora-
tion, 2005).
In order to combine the benefits of the two par-
adigms and to achieve a decentralized platform for
loosely coupled software components, an architecture
of a service-oriented middleware was proposed by
(Gerke et al., 2003). In order to implement this archi-
tecture, (Gerke and Stiller, 2005) presented a JXTA-
based middleware. This middleware enables a fully
distributed service market, in which peers provide ser-
vices to other peers. This middleware supports this
market by providing mechanisms to search within the
underlying distributed P2P network for services, to
negotiate the terms of service usage, and finally to
charge for service usage. The market itself offers low
entrance hurdles, as any Internet host can enter the
market by running this middleware implementation.
In addition to the usage of a single service by a
single peer, the middleware-enabled service market
makes it possible to combine services into new value-
added services. This process, called service compo-
sition, allows for the maximum benefit from service
reusability when creating new services. Thus, new
16
Gerke J., Reichl P. and Stiller B. (2005).
STRATEGIES FOR SERVICE COMPOSITION IN P2P NETWORKS.
In Proceedings of the Second International Conference on e-Business and Telecommunication Networks, pages 16-24
DOI: 10.5220/0001416100160024
Copyright
c
SciTePress
services can be deployed much quicker and the expert
knowledge of service developers can be used in new
services.
Service composition consists of two main sub prob-
lems: (a) understanding what functionality is pro-
vided by services and (b) understanding how services
communicate through their interfaces. The first prob-
lem has been tackled through the development of se-
mantic service descriptions (Hendler et al., 2002),
as well as through the application of artificial intel-
ligence (Carman et al., 2003). The second prob-
lem is addressed mainly through interface description
languages like WSDL (Web Services Descriptions
Working Group, 2005). Other interface standards like
CORBA do not offer the self-description capabilities
of web services, thus reducing the reusability of soft-
ware components.
The highest benefit from service composition
would be achieved, if it could be carried out by any
peer in a completely automated manner, at high speed,
and costs approaching zero. However, both sub prob-
lems described above have not yet been completely
solved. Therefore, for the time being, service com-
position can only be carried out by specialized peers,
called service composers at a certain cost.
Therefore, this paper investigates composition
strategies for service composers, while abstracting
from the detailed technique used. To this end, a gen-
eral algorithm for service composition is defined and
its evaluation is performed in a scenario, where com-
puting power is bought from various peers. Thus,
general influences of parameters onto this algorithm
are evaluated, and the welfare a service composer can
create is defined. The overall goal is to find a strategy
for service composition, which scales well while cre-
ating high welfare for service consumers and service
composers. How this welfare is distributed fairly be-
tween the two is out of the scope of this paper, but will
addressed elsewhere with the help of public auctions
(Varian, 2003).
The remainder of this paper is structured as fol-
lows. Section 2 gives an overview of the distributed
service market and the underlying P2P architecture.
Section 3 contains definitions of services, their prop-
erties and descriptions. Section 4 introduces the gen-
eral service composition algorithm proposed. While
Section 5 presents the evaluation of this algorithm
with different parameters, Section 6 concludes the
work and gives an overview over future work.
2 P2P SERVICE MARKET
Before investigating service composition, it is nec-
essary to describe the environment in which it takes
place. Thus, the underlying service-oriented P2P net-
work and roles being part of the system are outlined.
Additionally, the service market enabled by the un-
derlying P2P network and the markets for composed
services are discussed.
2.1 Underlying Technology
The P2P network is not a physical network, but is
built on top of the Internet (A. Oram (Editor), 2001).
This implies that peers are Internet hosts and links
of the P2P network are end-to-end (e2e) connections
through the Internet between such hosts. Thus, the set
of hosts taking part in the P2P network and the e2e
connections between them form an overlay network
on top of the Internet, consisting of peers and links.
In turn, the notion of terms like ’link’ or ’neighbor’ is
different in the Internet and in the overlay network. It
is assumed that connections provide an e2e quality of
service guarantees when required by services, regard-
less of the technology used to provide these guaran-
tees, e.g., IntServ or DiffServ.
Every peer inside the network can provide and re-
quest services to and from other peers. The term
service is defined as functionality which is offered
by a peer to other peers, and which can be accessed
through input and output interfaces. Services are
described through documents called service descrip-
tions, including service functionality and interfaces,
but also characteristics such as terms of usage, e.g.,
prices and methods of payment. Services can be used
by applications, which are programs running on peers
which are not provided as services themselves and of-
fer user interfaces.
A peer providing a service to another peer is acting
as a service provider, while a peer which is using a
service from another peer is acting as a service con-
sumer. A single peer can take over both roles succes-
sively or even at the same time, if he provides a set of
services to a set of peers and uses a set of other ser-
vices from another set of peers. The service usage is
always initiated by the service consumer, thus a ser-
vice provider can not supply unrequested services to
consumers or even demand payment for services de-
livered in such a fashion. Due to the dynamic nature
of P2P networks, the duration of a service usage is
restricted, i.e., it is not possible to rely on the avail-
ability of a certain service for weeks or months.
Service usage follows a one-to-one relationship be-
tween service consumer and provider, i.e., neither do
several service consumers use the same service in-
stance, nor do several service providers together pro-
vide a service to a consumer directly. Several ser-
vice consumers can still use the same service at the
same time, but several service instances are created by
the service provider and service usage takes place in-
dependently. Furthermore, service providers can use
services from other service providers, in order to pro-
STRATEGIES FOR SERVICE COMPOSITION IN P2P NETWORKS
17
vide a new value-added service to a service consumer.
This process of combining services is called service
composition. A peer carrying out this process is said
to play the role of a service composer. There is no di-
rect relation between additional service providers and
the service consumer. Examples of such service us-
ages are shown in Figure 1.
Peer 1
Peer 2
Peer 3 Peer 4
Application
Service Instance
Service
Service Provision
Figure 1: The use model (Gerke and Stiller, 2005)
2.2 Market Model
The service market consists of the peers which offer
services and use them, without composing new ser-
vices on demand. This service market is assumed to
be a global market with low entrance barriers, due
to its open P2P nature. This market is character-
ized through perfect competition between its partici-
pants since the number of market participants is large.
Therefore, if a peer was offering a service for a price
much higher than his own costs, another peer would
offer the same service at a lower price. Thus, prices
for services are set by the market itself through com-
petition, service prices are given and not negotiable.
Service providers do not have to price their services.
Either they are able to offer a service for the market
price or they do not offer the service at all.
Service
Consumer
(one)
Service
Composers
(a few)
Service
Suppliers
(many)
Services
Composed
Services
Service Market (with
Perfect Competition)
Composed Service
Market (Oligopoly)
Figure 2: The two markets model
However, the market model is clearly different
Table 1: Comparison of the Two Markets
Service Mar-
ket
Composed
Service
Market
No. of Sellers Many Some
No. of Buyers Many One
Market Form Perfect com-
petition
Oligopoly
Traded Good Services Composed
Services
Persistence Constant Created by re-
quest
Prices Set by market Pricing re-
quired
when service composition is considered. Service
composition is a complex process. Therefore, it is
assume that only a small number of peers decide to
take on the role of service composer. Each of them
carries out his own variant of service composition,
using his own business secrets. Service composers
act as brokers between service consumers and service
providers. They take part in the service market as buy-
ers and in the composed service market as sellers, as
shown in Figure 2.
Because of the high specialization required, only a
small number of overall peers will act as service com-
poser. Therefore, the market for composed services
will not have perfect competition but will be domi-
nated by an oligopoly of service composers. In fact,
there is a separate market for every new composed
service. It is created whenever a service consumer
contacts an oligopoly of service composers with the
request to compose a new service. Thus, pricing is
an important issue in the composed services market,
as a price has to be found for a previously inexistent
service. Table 1 covers key properties of these two
markets.
3 SERVICE PROPERTIES
Due to the market-based view and discussion above,
goods traded need a formal definition. Therefore, ser-
vices must be described by specifying their properties
as well as the implications of these properties are ex-
plained.
(American Heritage Dictionaries (Editor), 2000)
defines a service as an act or a variety of work
done for others, especially for pay. In the scope of
this paper, this definition is applied only to the en-
visioned technical system and its participants (the
peers). Thus, a service is a piece of software or a
software component operated by one of the systems
ICETE 2005 - GLOBAL COMMUNICATION INFORMATION SYSTEMS AND SERVICES
18
participants. It fulfills one or several tasks on behalf
of another participant of the system, thus carrying out
work for him, for which he is paid.
Every service S has properties S
=
(S
1
, ..., S
n
), n N which describe the char-
acteristics of the service (Dumas et al., 2001),
especially the task which is carried out by the ser-
vice. These properties may include parameters and
information from four different groups:
Functionality: A formal description of what the
service should do (if specified by the service con-
sumer) or what it can do (if specified by the service
provider)
Quality: A list of QoS parameters which describe
with which quality the service should be provided
(if specified by the service consumer) or can be pro-
vided (if specified by the service provider). All pa-
rameters can have fixed values or can be described
with value ranges.
Cost: A tariff (Reichl and Stiller, 2001) used to
charge the consumption of the service (if specified
by the service provider, the actual cost is calculated
by applying the tariff to the functionality and qual-
ity properties measured during the service delivery)
or the willingness-to-pay function (if specified by
the service consumer) which describes how much
the consumer is willing to pay for a service depend-
ing on its functionality and quality parameters.
Others: Who is providing/requesting the service.
Based on these definitions and explanations of ser-
vices and their properties the following formalized
approach is taken.
Service properties are specified in service descrip-
tions, where every property S
x
consists of a for-
mal property description S
′′
x
and a property range
S
x
= [S
x
,
S
x
]. The property description describes
the meaning of properties according to a common se-
mantic standard shared by all peers (Hendler et al.,
2002). The property range describes the degree of
fulfillment of this property in numerical values. Met-
rics generating these values are part of the property
description.
Two property descriptions match when they are se-
mantically equal according to the common semantic
standard. Thus, a property A
x
is said to fulfill an-
other property B
y
, if and only if, A
′′
x
matches B
′′
x
and
their property ranges overlap, i.e., B
x
A
x
B
x
or B
x
A
x
B
x
. Analogously, a property A
x
is
said to exactly fulfill another property B
y
, if and only
if, A
′′
x
matches B
′′
x
and A
x
= B
x
and
A
x
=
B
x
.
Then, a service S with properties S
=
(S
1
, ..., S
n
), n N is said to implement a service de-
scription D with properties D
= (D
1
, ..., D
m
), m
N, if and only if, all its properties fulfill the proper-
ties specified in the service description, i.e., n = m
and i [1, n] : S
i
fulfills D
i
. Analogously, a ser-
vice S with properties S
= (S
1
, ..., S
n
), n N is
said to exactly implement a service description D with
properties D
= (D
1
, ..., D
m
), m N, if and only
if, n = m and i [1, n] : S
i
exactly fulfills D
i
.
Thus, a service S is called an (exact) implementation
of a service description D, if and only if, S (exactly)
implements D. Vice versa, a service description D
is said to (exactly) describe a service S, if and only
if, S (exactly) implements D. It is assumed that ex-
act service descriptions exist and have been published
within the P2P network for all services offered by
peers acting as service providers. Of course, service
descriptions can exist without corresponding imple-
mentations.
Even if a consumer specifies fixed property val-
ues in a service description, an infinite number of
different services can implement his service descrip-
tion. Thus, a service class is defined as a set of
services which has specific common properties. Let
S = {S
1
, ..., S
n
}, n N be the set containing all
services and let D be a service description with prop-
erties D
= (D
1
, ..., D
m
), m N. Then,
b
D is called
a service class for a service description D, if and only
if,
b
D = {S
x
|S
x
implements D}, S
x
S. All ser-
vices which have these properties are called members
of the service class. Let C be the service class for
a service description D. Then, a service S is called
a member of C, if and only if, S implements D.
Thus, every implementation of a service description
is a member of the service class created by the de-
scription. Furthermore, every service description au-
tomatically creates a service class, though this class
does not need to have any members.
4 SERVICE COMPOSITION
From the service composers point of view, the service
composition process starts when he receives a service
description from a service consumer. The service con-
sumer does not have to state fixed service properties
within this description, but can make use of property
ranges as defined in Section 3.
After receiving the consumers service description,
the composer searches the P2P network for member
services of the service class described by this descrip-
tion. If he can not find such a service, he starts com-
posing the service by combining other services. In
order to do this, he must obtain or create a building
plan (Gerke, 2004), which describes how to achieve
the properties of the original service class by combin-
STRATEGIES FOR SERVICE COMPOSITION IN P2P NETWORKS
19
ing members from other service classes. Generally,
a building plan describes how members of a specific
service class can be combined with members of other
specific service classes to create a new composed ser-
vice. In particular, it describes properties of the com-
posed service and how these properties relate to the
properties of its component services. This process is
supported by the mapping m in such a way that if
D is a service with properties D
, then B is called a
building plan for D, if and only if, B contains service
descriptions {D
1
, ..., D
n
}, n (N ) and a mapping
m : D
1
× ... × D
n
D
which describes the re-
lation between properties of component services (i.e.,
specific services fulfilling the service descriptions) on
the properties of the composed service (i.e., the ser-
vice created by composing the component service as
also described in the building plan).
When the composer has obtained one or several
building plans for the service class described by the
consumers service description, he searches the P2P
network for implementations of the service classes
described within them. If he is unable to find any of
these service classes, he recursively creates building
plans for this service class. Thus, he creates a service
dependency graph, as shown in Figure 3.
Initial
Service Class
Service
Class 4
Service
Class 3
Implementation 6
Implementation 7
Implementation 5
Implementation 1
Building Plan 1
Service
Class 2
Service
Class 1
Implementation 4
Implementation 2
Building Plan 3
Cover
“and” node
“or” node
Service Class
Building Plan
Service Implementation
Building Plan 2
Figure 3: An example service dependence tree
The original service class (described by the con-
sumers service description) is the root of this tree.
Several ways to implement this service (one imple-
mentation and two building plans) are connected to
the root node via an or node, while service classes are
connected to the building plan via and nodes. Com-
posed services can be found by traversing the tree
from its root node. At each or node exactly one link
must be chosen for traversal, while at each and node
all links have to be traversed. A sub tree found by
applying this algorithm models a composed service
when only services form this trees leaves. Such a tree
is called a cover of the original service dependency
tree and is also shown in Figure 3. The algorithm does
rate the quality of a composed service in any way.
Building plans only ensure that every composed ser-
vice fulfills the consumers initial service description
(i.e., the functionality is the same and all properties
overlap with described properties).
The following pseudo code defined a recursive al-
gorithm to build a service dependence tree.
buildDependenceTree(ServDescr SC) {
while (ServDescr SI =
searchNewServiceImplementation (SC)
!= nil) {
buildDependenceTree (SI);
SC.addChild (SI);
}
while (BuildingPlan BP =
searchNewBuildingPlan (SC) != nil) {
for (int i=0; i <
BP.getChildren().length; i++)
buildDependenceTree
(BP.getChildren()[i];
SC.addChild (BP);
}
}
In order to achieve this presentation, slightly sim-
plified, the following assumptions have been made:
The classes ServiceDescription and BuildingPlan
are tree nodes.
The and and or nodes are neglected. All children of
a ServiceDescription are inherently connected via
an or node and all children of a BuildingPlan are
inherently connected via an and node.
Each new BuildingPlan already comes with Ser-
viceClass children (instead of connecting them by
hand according to service descriptions).
The algorithm describes a general way to build ser-
vice dependence trees. By using it, any kind of ser-
vice dependence tree can be created. The decision
about what tree is created is made by the two func-
tions searchNewServiceImplementation and search-
NewBuildingPlan. These methods include individual
secrets of each service composer, namely:
How to find a new building plan or service imple-
mentation for a given service description.
When to stop searching for a new building plan or
service implementation.
5 EVALUATION
The general service algorithm described in Section 4
has been evaluated by simulations. The service re-
quested in these simulations is a computing service
with a computing power measured in GFLOPS (bil-
lions of floating point operations per second). Dif-
ferent strategies for when to stop searching for more
building plans are evaluated. The criteria for evalua-
tion is the achieved average welfare W (S) of a com-
posed service S. The welfare of a composed service
depends on the utility U(S) the consumer receives
ICETE 2005 - GLOBAL COMMUNICATION INFORMATION SYSTEMS AND SERVICES
20
from the service, the cost of the service C(S), and
the cost for composing the service B(S) in such a
way that W (S) = U(S) C(S) B(S) holds. The
cost of the composed service is equal to the sum of
the costs of the services needed to create it. I.e., let
S
1
...S
i
, i [1, m] be the services used to create the
composed service S, then C(S) =
P
m
i=1
C(S
i
).
5.1 General Assumptions
The simulations make the following assumptions:
The code to be executed with the computing power
can be parallelized to a granularity of 1 GFLOPS,
which is also the smallest amount which can be
bought as a single service.
The parallelization incurs no extra effort. Espe-
cially, no additional synchronization or signalling
overhead must be taken into account.
Any amount of required GFLOPS can be bought
directly as a service implementation from at least
one service provider. This assumption is reason-
able due to the perfect competition existing in the
service market.
For any amount of GFLOPS five building plans ex-
ist, which describe how to obtain the GFLOPS by
buying two GFLOPS shares instead. This assump-
tion is not stringent, as there are not many dif-
ferences between finding a bad building plan and
finding none at all. Plans describe 0.9/0.1 (worst),
0.8/0.2, 0.7/0.3, 0.6/0.4 and 0.5/0.5 (best) ratios of
the original amount of GFLOPS.
The cost of finding a new building plan or finding
out that no more building plan exist is fixed and
is equal to . However, it is also assumed that the
service composer has no previous knowledge of the
cost, i.e., only after every search for building plan
does he know what this search did cost.
The cost of finding service implementations is neg-
ligible, as this functionality is provided by the ser-
vice search of the underlying P2P network. Thus,
let n be the number of searched building plans, then
B(S) = n · Z.
The utility function of the service consumer is in-
creasing monotonously and it is convex, based on
the amount of GFLOPS received. Thus, additional
utility created by additional amounts of GFLOPS
decreases monotonously.
Since there is perfect competition in the service
market, all service providers use a similar cost
function. This cost function is increasing monoto-
nously and it is concave, based on the amount of
GFLOPS received. Thus, the cost of additional
GFLOPS is monotonously increasing.
Properties are fixed. This means, that the service
consumer does not specify a range of GFLOPS, but
rather a precise amount of GFLOPS. Since build-
ing plans define exact ratios for their two respec-
tive component services, the amount of GFLOPS
in service classes and service implementations also
becomes fixed.
5.2 Simulation Setup
The service composition algorithm was implemented
in Java and executed with different search strategies
and parameters. Simulations were carried out on a
PC with 512 MB memory and a 1.8 GHz CPU. For all
settings, the average welfare was calculated as the av-
erage over 100 simulation runs. In all simulations the
amount of the requested computing power has been
set to 1024 GFLOPS. The cost function used in those
simulations is C(x) =
x
2
10000
, the utility function is
U(x) = log x · 10 (x being the number of GFLOPS),
as shown in Figure 4.
0 100 200 300 400 500 600 700 800 900 1000
0
10
20
30
40
50
60
70
80
90
100
GFLOPS
Utility and Cost
cost
utility
Figure 4: Utility and cost functions
5.3 Balanced Search
The algorithm used to build the service dependence
tree is constructed from the root as a balanced tree.
This means that for every service class in the tree
the same amount of searches for building plans is
carried out until the previously defined search depth
is reached. Figure 5 depicts the welfare for differ-
ent costs of finding building plans, when building
plans are only searched once, i.e., no recursion takes
place (strategy #1). Vice versa, Figure 6 depicts the
welfare for different costs of finding building plans,
when recursion takes place until a certain tree depth
is reached. At all steps only a single building plan is
searched (strategy #2).
Both strategies produce good results for the aver-
age cost for searching building plans of 3. Thus, this
STRATEGIES FOR SERVICE COMPOSITION IN P2P NETWORKS
21
1
2
3
4
5
6
0
2
4
6
−15
−10
−5
0
5
10
15
20
No. of Building Plans
Building Plan Cost
Welfare
Figure 5: Welfare for different numbers of building plan
searches and different building plan costs
cost was chosen for strategy #3, which investigated,
whether the welfare could be increased by varying the
number of building plans searched at every step, as
well as the tree depth. However, the results depicted
in Figure 7 clearly show, that the increased benefit
achieved by building a wide and deep service depen-
dency tree is by far outweighed by the increased cost
for building this tree. In order to optimize the welfare,
more sophisticated heuristics for influencing the trees
width and depth are required.
1
2
3
4
5
6
0
2
4
6
−300
−200
−100
0
100
Tree Depth
Building Plan Cost
Welfare
Figure 6: Welfare for different service dependency tree
depths and different building plan search costs
5.4 Search Until Welfare Decreases
In order to avoid search cost explosions (cf. Figure
7), the service composition algorithm was extended
with strategy #4: The service dependency tree is built
recursively without a predefined search depth. The
recursion is stopped when the previous search for a
building plan has created less additional benefit than
the search cost, i.e., the welfare decreased
1
2
3
4
1
1.5
2
2.5
3
3.5
4
−7000
−6000
−5000
−4000
−3000
−2000
−1000
0
1000
Tree Depth
No. of Building Plans
Welfare
Figure 7: Average welfare for different numbers of building
plan searches and different service dependency tree depths,
with fixed building plan cost of 3
Strategy #4 is clearly not optimal, as the next search
for a building plan could still provide a higher benefit.
However, results depicted in Figure 8 clearly show
that this strategy makes the algorithm resistant against
high building plan search costs. Still, the algorithm
produces bad results for higher numbers of building
plans searched.
0
5
10
15
1
1.5
2
2.5
3
−8000
−6000
−4000
−2000
0
2000
No. of Building Plans
BP search cost
Welfare
Figure 8: Average welfare for different numbers of building
plan searches and building plan search costs, using the local
welfare decrease heuristic
5.5 Tree Width Decreases with
Increasing Tree Depth
Strategy #5 makes the following extension to the
previous one: If the search continues (i.e., the last
search step produced additional welfare), the number
of building plans searched will be decreased by one in
comparison to the previous search step. This strategy
outperforms the previous one in all cases except one:
When initially only a single building plan is searched
ICETE 2005 - GLOBAL COMMUNICATION INFORMATION SYSTEMS AND SERVICES
22
the tree depth will only be 1 and the resulting welfare
will be equal to the welfare as depicted in Figure 9 for
the search of a single building plan.
0
5
10
15
0
2
4
6
−6000
−4000
−2000
0
2000
No. of Building Plans
BP search cost
Welfare
Figure 9: Average welfare for strategy #5
5.6 Tree Width Decreasing with
Welfare Decrease
Finally, strategy #6 computes the number of building
plans depending on the size of the additional welfare
created in the last search step. The welfare divided
by the cost for searching the building plan equals the
number of building plans to be searched next. This
strategy performs worse than the previous one for
higher numbers of initially searched building plans,
but always creates higher welfare for a maximum
number of searched building plans of 1.
0
5
10
15
1
2
3
4
−2.5
−2
−1.5
−1
−0.5
0
0.5
x 10
4
No. of Building Plans
BP search cost
Welfare
Figure 10: Average welfare for strategy #6
5.7 Discussion
The set of strategies show a number of different
heuristics. However, measuring scalability requires
to count the number of searches for building plans
carried out, which have been omitted in detail for
space reasons, but they are part of the calculated wel-
fare in the form of the cost for building the service
dependence tree. Thus, the depicted welfare func-
tions clearly show the influence of bad scalability in
the rapid drops of welfare due to a high number of
searches for building plans.
1 2 3 4 5 6 7 8 9 10 11
−20
−10
0
10
20
30
40
50
Building plan cost
Welfare
strategy #1, best results
strategy #2, best results
strategy #4, 1 BP
strategy #5, 2 BPs
strategy #6, 1 BP
Figure 11: Comparison of optimal sub-strategies
On one hand, simulation results show that all strate-
gies produce bad results when building a wide ser-
vice dependence tree, i.e., when searching for several
building plans for a single service class. On the other
hand, results indicate that controlling the depth of the
tree, i.e., deciding when to stop the recursion, can be
handled very well by strategies. For each of theses
strategies an optimal sub-strategy exists. Strategy #4
and #6, produce their highest welfare when at each
algorithm step a single building plan at the most is
searched. Strategy #5, produces its highest welfare
when initially searching for two building plans. Wel-
fare of these sub strategies are compared in Figure 11.
It can be clearly seen, that strategy #4 outperforms
all other strategies. Furthermore, it produces higher
welfare than the theoretical hulls of strategies #1 and
#2, which were created by manually selecting the best
sub strategy for each building plan search cost. Thus,
for any building plan search cost investigated the de-
scribed sub strategy #4 is the best choice. Further-
more, the results depicted in Figure 11 indicate that
for high building plan search costs strategy #4 pro-
duces the same welfare as the hulls of strategy #1 and
#2. This is logical, since for high building plan search
costs no profit can be made, in which case all three
strategies will stop after a single search for a building
plan.
STRATEGIES FOR SERVICE COMPOSITION IN P2P NETWORKS
23
6 SUMMARY
Different strategies for service composition in P2P
networks have been investigated. Based on the dis-
tributed and decentralized service market together
with its underlying P2P network, the service market
model was extended by the composed service market.
Driven by models of all building blocks for the service
composition process the generic service composition
algorithm was specified, resulting in service depen-
dence trees. Different strategies for building this tree
were developed and evaluated in simulations of com-
posing a distributed computing service.
Such strategies for building the service dependence
tree can differ in the width of the tree (i.e., how many
building plans are searched for each service class)
and the depth of the tree (i.e., when to stop the re-
cursion of the tree building algorithm). Those results
show that extending the tree and the width at the same
time quickly leads to a dropping welfare of several or-
ders of magnitude. However, improved heuristically
strategies control the width and depth of the tree. All
strategies proved to be very sensitive to the number
of building plans searched at each step. Not a single
heuristic was able to produce a high (or even posi-
tive) welfare, when a larger number of building plans
could be searched for. In fact, these results indicate
that at the most two building plans should be searched
for within any service class. If those strategies were
used in this way, they produced positive welfare for
most of the investigated spectrum of building plan
search costs. One strategy produced positive welfare
for the whole spectrum, and continually outperformed
all other strategies.
Thus, it has been shown that service composition
can be economically successful, when a generic algo-
rithm is used with the proposed strategies and a small
number of building plans searched for at each step.
Future work includes the development of public auc-
tions for composed services, thus enabling the service
consumer to publish his utility function, which in turn
enables the maximization of the welfare of the com-
posed service market.
This work has been partially performed in the EU-
projects MMAPPS and DAIDALOS, and the Austrian
Kplus competence center programme.
REFERENCES
A. Oram (Editor) (2001). Peer-to-Peer: Harnessing the
Power of Disruptive Technologies. OReilly.
American Heritage Dictionaries (Editor) (2000). The Amer-
ican Heritage Dictionary of the English Language.
Houghton Mifflin, 4th edition.
Blizzard Corporation (2005). Blizzard Downloader
F.A.Q. http://www.worldofwarcraft.com/
info/faq/blizzarddownloader.html.
Carman, M., Serafini, L., and Traverso, P. (2003). Web
service composition as planning. In In ICAPS 2003
Workshop on Planning for Web Services, Trento, Italy.
Dumas, M., O’Sullivan, J., Heravizadeh, M., ter Hofst-
ede, A., and Edmond, D. (2001). Towards a semantic
framework for service description. In In IFIP Confer-
ence on Database Semantics, Hong Kong, China.
Gerke, J. (2004). Service composition in peer-to-peer sys-
tems. In At the Dagstuhl Seminar on Peer-to-Peer Sys-
tems and Applications, Dagstuhl, Germany.
Gerke, J., Hausheer, D., Mischke, J., and Stiller, B. (2003).
An architecture for a serviceoriented peer-to-peer sys-
tem (sopps). In In Praxis der Informationsverar-
beitung und Kommunikation (PIK), No. 2.
Gerke, J. and Stiller, B. (2005). A service-oriented peer-to-
peer middleware. In In Conference on Kommunikation
in Verteilten Systemen KiVS05, Kaiserslautern, Ger-
many. in Informatik Aktuell, Springer.
He, H. (2003). What is Service-Oriented Archi-
tecture? In OReilly webservices.xml.com,
http://webservices.xml.com/pub/a/
ws/2003/09/30/soa.html.
Hendler, J., Berners-Lee, T., and Miller, E. (2002). Integrat-
ing applications on the semantic web. In In Journal
of the Institute of Electrical Engineers of Japan, Vol
122(10).
Izal, M., Urvoy-Keller, G., Biersack, E., Felber, P., Hamra,
A. A., and Garces-Erice, L. (2004). Dissecting bittor-
rent: Five months in a torrent’s lifetime. In In Pas-
sive and Active Measurements (PAM), Antibes Juan-
les-Pins, France.
Microsoft Developer Network (2004). .NET Framework
Product Overview. http://msdn.microsoft.
com/netframework/technologyinfo/
overview/.
Reichl, P. and Stiller, B. (2001). Nil nove sub sole? why
internet tariff schemes look like as they do. In In 4th
Internet Economics Workshop (IEW’01), Berlin, Ger-
many.
Varian, H. (2003). Intermediate Microeconomics: A Mod-
ern Approach. Norton, W. W. & Company.
Web Services Descriptions Working Group (2005). Web
Services Description Language (WSDL) Version 2.0.
http://www.w3.org/2002/ws/desc.
World Wide Web Consortium (2004). Web Services Ac-
tivity Statement. http://www.w3c.org/2002/
ws/Activity.
ICETE 2005 - GLOBAL COMMUNICATION INFORMATION SYSTEMS AND SERVICES
24
